Atlas Copco PF4000-C-PB-HW電源對焦模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
一、產品概述
Atlas Copco PF4000-C-PB-HW 是 PF4000 系列中集成 PROFIBUS 通信接口（PB） 的一款高性能 電源控制/對焦模塊。該模塊用于驅動和控制 Atlas Copco 的智能電動擰緊工具（如 Tensor ST、ES、ETX 系列），提供穩定電源、對焦控制以及擰緊過程數據通信功能，尤其適用于需要工業總線通信和過程控制的高端裝配場合。
二、技術參數（簡要）
電源輸入：100–240V AC，50/60Hz
通信協議：PROFIBUS-DP（硬件集成接口）
支持工具類型：Atlas Copco Tensor ST/ES/ETX 系列等
控制方式：扭矩控制 / 角度控制 / 多級階段擰緊
集成功能：數據采集、故障診斷、程序參數下載、實時監控
安裝方式：標準工業機柜或產線嵌入安裝
三、應用領域
1. 汽車制造
主要用于總裝車間的底盤、動力系統、內飾系統螺栓連接
針對高重復性、批量化生產的裝配工序，確保一致性和安全性
支持與 PROFIBUS 總線的工廠自動化控制系統集成，實現集中管理
2. 工程機械與軌道交通
工程機械車架、傳動系統的高強度螺紋連接任務
列車底盤、電氣箱、高壓連接件的精密螺栓控制
3. 新能源行業
動力電池包、電驅系統裝配中關鍵部件的扭矩控制
電池冷卻系統螺栓的分階段緊固
4. 航空航天
飛機結構件、艙體、起落架等高精度緊固任務
需要全程記錄和追溯的裝配質量控制要求
5. 家電與電子設備制造
高速生產線上的電子產品精密裝配
擰緊扭矩范圍小但精度要求高的自動化作業
6. 工業自動化裝配線
與 PLC、機器人系統配合進行自動擰緊任務
適用于柔性產線、無人產線、智能制造系統
英文資料：
1、 Product Overview
Atlas Copco PF4000-C-PB-HW is a high-performance power control/focusing module integrated with PROFIBUS communication interface (PB) in the PF4000 series. This module is used to drive and control Atlas Copco's intelligent electric tightening tools (such as Tensor ST, ES, ETX series), providing stable power supply, focus control, and tightening process data communication functions, especially suitable for high-end assembly occasions that require industrial bus communication and process control.
2、 Technical parameters (brief)
Power input: 100-240V AC, 50/60Hz
Communication protocol: PROFIBUS-DP (Hardware Integrated Interface)
Supported tool types: Atlas Copco Tensor ST/ES/ETX series, etc
Control mode: torque control/angle control/multi-stage tightening
Integrated functions: data collection, fault diagnosis, program parameter download, real-time monitoring
Installation method: Embedded installation in standard industrial cabinets or production lines
3、 Application Fields
1. Automobile manufacturing
Mainly used for bolted connections of chassis, power system, and interior system in the final assembly workshop
Ensure consistency and safety for assembly processes with high repeatability and mass production
Support integration with PROFIBUS bus for factory automation control system, achieving centralized management
2. Construction Machinery and Rail Transit
High strength threaded connection task for construction machinery frame and transmission system
Precision bolt control of train chassis, electrical box, and high-voltage connectors
3. New energy industry
Torque control of key components in the assembly of power battery packs and electric drive systems
Staged tightening of bolts for battery cooling system
4. Aerospace
High precision fastening tasks for aircraft structural components, cabins, landing gear, etc
Assembly quality control requirements that require full process recording and traceability
5. Manufacturing of household appliances and electronic devices
Precision assembly of electronic products on high-speed production lines
Automated operations with small tightening torque range but high precision requirements
6. Industrial automated assembly line
Cooperate with PLC and robot systems for automatic tightening tasks
Suitable for flexible production lines, unmanned production lines, and intelligent manufacturing systems
