Tokyo Electron 3M81-005973-14輸入輸出模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
TEL Tokyo Electron 3M81-005973-14 輸入輸出模塊簡介
一、基本信息
產品型號： 3M81-005973-14
名稱定義： 輸入輸出模塊（I/O Module）或稱為 SFLUX-AMP PCB（信號放大板）
制造商： Tokyo Electron Ltd.（TEL）
適用設備： 半導體工藝設備，如CVD、Etcher、Coater/Developer等平臺控制系統中
二、功能與作用
信號輸入輸出接口
接收和輸出數字或模擬信號，用于與現場設備（如傳感器、執行器、電磁閥等）建立通信通道。信號放大與整形
集成有信號放大電路（SFLUX-AMP），可對輸入信號進行增強或?yàn)V波，提升信號質量與穩定性。電氣隔離功能
可能具備隔離電路設計，有助于抑制電磁干擾，保護上位控制系統的穩定運行。模塊化集成
可與CPU模塊、繼電器控制板、電源模塊等組合組成完整的控制系統，便于替換與維護。
三、典型應用領域
氣體供應系統：控制氣閥開閉、采集傳感器狀態。
溫控與工藝單元：輸入溫度、壓力等模擬量信號，輸出控制指令。
自動化搬運系統：與機械臂、升降平臺、傳送帶等設備進行交互控制。
真空或清洗設備：反饋腔體壓力、門狀態、水氣開關等狀態信息。
英文資料：
Introduction to TEL Tokyo Electron 3M81-005973-14 Input/Output Module
1、 Basic Information
Product model: 3M81-005973-14
Name definition: Input/Output Module (I/O Module) or SFLUX-AMP PCB (Signal Amplification Board)
Manufacturer: Tokyo Electron Ltd. (TEL)
Applicable equipment: Semiconductor process equipment, such as CVD, Etcher, Coater/Developer and other platform control systems
2、 Function and Function
Signal input/output interface
Receive and output digital or analog signals for establishing communication channels with field devices such as sensors, actuators, solenoid valves, etc.
Signal amplification and shaping
Integrated with signal amplification circuit (SFLUX-AMP), it can enhance or filter the input signal to improve signal quality and stability.
Electrical isolation function
Possible isolation circuit design can help suppress electromagnetic interference and protect the stable operation of the upper control system.
Modular integration
It can be combined with CPU modules, relay control boards, power modules, etc. to form a complete control system, making it easy to replace and maintain.
3、 Typical application areas
Gas supply system: Control the opening and closing of gas valves and collect sensor status.
Temperature control and process unit: Input analog signals such as temperature and pressure, and output control commands.
Automated handling system: interacts and controls with equipment such as robotic arms, lifting platforms, and conveyor belts.
Vacuum or cleaning equipment: feedback on chamber pressure, door status, water and gas switch status information.
2.產 品 展 示
