Tokyo Electron 2L87-132494-12伺服電機 PDF資料
1.產 品 資 料 介 紹：
中文資料：
一、基本信息
產品型號： 2L87-132494-12
產品名稱： 伺服電機（Servo Motor）
制造商： Tokyo Electron Ltd.（TEL）
產品類別： 精密電機驅動部件
典型用途： 用于TEL半導體設備中的晶圓搬運、定位、旋轉等自動化系統
二、主要功能
高精度位置控制
該伺服電機與編碼器協同工作，實現微米級位置反饋和高速動態響應，用于機械臂、平臺滑軌、載物臺的精準移動。閉環伺服反饋系統
搭載絕對值或增量式編碼器，電機狀態實時反饋至主控制器，保證運動過程的閉環控制與安全。高可靠性與潔凈室適應性
采用低發塵材料、密封結構，符合半導體潔凈環境等級要求，支持 24 小時連續運轉。
三、典型應用場景
晶圓裝載單元（Load Port）：控制機械手或升降裝置，實現晶圓精準放置。
涂膠顯影系統（Coater/Developer）：用于旋轉平臺或工藝腔體定位機構。
蝕刻或CVD設備：驅動氣閥控制系統或進樣/出樣移動裝置。
自動對位系統：實現高速對準、升降、偏移修正等動作控制。
英文資料：
1、 Basic Information
Product model: 2L87-132494-12
Product Name: Servo Motor
Manufacturer: Tokyo Electron Ltd. (TEL)
Product Category: Precision Motor Drive Components
Typical use: Used for automated systems such as wafer handling, positioning, and rotation in TEL semiconductor equipment
2、 Main functions
High precision position control
This servo motor works in conjunction with an encoder to achieve micrometer level position feedback and high-speed dynamic response, used for precise movement of robotic arms, platform slides, and stages.
Closed loop servo feedback system
Equipped with absolute or incremental encoders, the motor status is fed back to the main controller in real-time, ensuring closed-loop control and safety during the motion process.
High reliability and cleanroom adaptability
Adopting low dust materials and sealed structure, it meets the requirements of semiconductor clean environment level and supports 24-hour continuous operation.
3、 Typical application scenarios
Load Port: Control the robotic arm or lifting device to achieve precise placement of wafers.
Coater/Developer: Used for rotating platforms or process chamber positioning mechanisms.
Etching or CVD equipment: Drive gas valve control system or sample injection/extraction moving device.
Automatic alignment system: realizes high-speed alignment, lifting, offset correction and other action control.
2.產 品 展 示
