Tokyo Electron 1B80-002788-11傳感器板 PDF資料
1.產 品 資 料 介 紹：
中文資料：
一、基本信息
型號：1B80-000226-13
類型：傳感器信號采集板 / Sensor Input Board
生產廠商：Tokyo?Electron (TEL)
二、主要功能
檢測信號采集：接收溫度、壓力、流量、濕度等多種傳感器信號。
信號轉換：將模擬信號（如 4?20?mA、0?10?V）或數字信號轉換為控制系統可識別的格式。
信號隔離與抗干擾：通過光耦或隔離放大器提高精度與穩定性。
反饋給主控單元：將處理后的數據通過背板總線或通信總線傳送給 CPU 或控制器模塊。
三、典型應用
CVD/ALD/Etcher 等工藝設備：用于監測反應腔體的溫度和壓力。
氣體控制系統：采集流量計與壓力傳感器的信號，實現工藝控制。
溫控與冷卻系統：采集熱電偶/RTD 的溫度信號，用于閉環溫控系統。
安全控制：通過多路傳感器監測設備狀態，提高操作可靠性與安全性。
四、推測技術特性
支持多路輸入信號通道（具體通道數需查證）
接口類型可能包括螺絲端子或DIN插頭
工業級隔離設計，適合潔凈室運行環境
與 TEL 常見平臺（如 Trias、Unity?II、Celesta）兼容
英文資料：
1、 Basic Information
Model: 1B80-000226-13
Type: Sensor Signal Acquisition Board/Sensor Input Board
Manufacturer: Tokyo Electron (TEL)
2、 Main functions
Detection signal acquisition: Receive various sensor signals such as temperature, pressure, flow rate, humidity, etc.
Signal conversion: Convert analog signals (such as 4-20mA, 0-10V) or digital signals into a format recognizable by the control system.
Signal isolation and anti-interference: Improve accuracy and stability through optocouplers or isolation amplifiers.
Feedback to the main control unit: Transfer the processed data to the CPU or controller module through the backplane bus or communication bus.
3、 Typical applications
CVD/ALD/Etcher and other process equipment: used to monitor the temperature and pressure of the reaction chamber.
Gas control system: Collect signals from flow meters and pressure sensors to achieve process control.
Temperature control and cooling system: Collect temperature signals from thermocouples/RTDs for closed-loop temperature control systems.
Safety control: By monitoring equipment status through multiple sensors, operational reliability and safety are improved.
4、 Speculate on technical characteristics
Support multiple input signal channels (specific number of channels to be verified)
Interface types may include screw terminals or DIN plugs
Industrial grade isolation design, suitable for clean room operating environment
Compatible with common TEL platforms such as Trias, Unity II, Celesta
