Tokyo Electron 308-500221-1光纖接口板 PDF資料
1.產 品 資 料 介 紹：
中文資料：
TEL Tokyo Electron 308-500221-1 光纖接口板（Fiber Optic Interface Board） 是一款用于 Tokyo Electron 半導體設備中的高速光纖通信接口板，主要負責設備內部或與外部系統之間的光纖數據傳輸。它支持高帶寬、低延遲的數據通信，廣泛用于工藝控制系統、圖像處理模塊、遠程診斷等對實時性要求較高的場合。
以下是詳細的產品應用領域說明（無圖案）：
一、基本信息
產品型號： 308-500221-1
產品名稱： 光纖接口板（Fiber Optic Interface Board）
制造商： Tokyo Electron Ltd.（TEL）
功能類別： 通訊/數據傳輸類模塊
板卡類別： 高速數字信號傳輸板（光電轉換型）
二、主要功能
光纖數據收發接口
實現電子信號與光信號的相互轉換；
支持單?；蚨嗄９饫w輸入輸出，用于高速數據交換。
設備間高速通信橋接
在主控制器與遠程模塊（如圖像處理單元、真空控制器、射頻電源控制單元）之間建立高速連接；
避免傳統電纜信號在復雜工業環境中受干擾的風險。
數據同步與實時反饋
提供低延遲通信機制，確保系統響應時間滿足半導體工藝精度要求；
支持數據完整性校驗、時鐘同步機制。
安全與電氣隔離
通過光纖天然的電氣隔離特性，防止設備間高壓干擾或浪涌傳導；
降低設備通信接口的故障率。
英文資料：
TEL Tokyo Electron 308-500221-1 Fiber Optic Interface Board is a high-speed fiber optic communication interface board used in Tokyo Electron semiconductor equipment, mainly responsible for fiber optic data transmission within the equipment or between external systems. It supports high bandwidth, low latency data communication and is widely used in process control systems, image processing modules, remote diagnostics, and other applications that require high real-time performance.
The following is a detailed explanation of the product's application areas (without patterns):
1、 Basic Information
Product model: 308-500221-1
Product Name: Fiber Optic Interface Board
Manufacturer: Tokyo Electron Ltd. (TEL)
Function category: Communication/Data Transmission Module
Board type: High speed digital signal transmission board (photoelectric conversion type)
2、 Main functions
Fiber optic data transceiver interface
Realize the mutual conversion between electronic signals and optical signals;
Supports single-mode or multi-mode fiber optic input and output for high-speed data exchange.
High speed communication bridge between devices
Establish high-speed connections between the main controller and remote modules such as image processing units, vacuum controllers, and RF power control units;
Avoid the risk of traditional cable signals being interfered with in complex industrial environments.
Data synchronization and real-time feedback
Provide a low latency communication mechanism to ensure that the system response time meets the precision requirements of semiconductor processes;
Support data integrity verification and clock synchronization mechanism.
Safety and electrical isolation
By utilizing the natural electrical isolation properties of optical fibers, high voltage interference or surge propagation between devices can be prevented;
Reduce the failure rate of device communication interfaces.
2.產 品 展 示
