Tokyo Electron 1B80-002394-11添加板 PDF資料
1.產 品 資 料 介 紹：
中文資料：
TEL Tokyo Electron 1B80-002394-11 添加板（Add-On Board） 是一塊安裝在東京電子（TEL）半導體設備主控制系統或功能模塊中的擴展電路板，用于增強現有主板的功能、增加I/O接口、支持特定信號處理或通信擴展，是設備模塊化設計的重要體現。
一、產品基本信息
| 項目 | 內容 |
|---|---|
| 產品名稱 | 添加板 / 擴展板（Add-On Board） |
| 產品型號 | 1B80-002394-11 |
| 所屬品牌 | Tokyo Electron Ltd.（東京電子） |
| 安裝方式 | 插接式或堆疊式連接于主控板或子系統模塊上 |
二、主要功能
功能擴展
為主控制板或I/O控制系統提供附加功能，如額外的輸入/輸出通道、模擬信號處理、溫度/壓力接口、光耦隔離等。
通信接口拓展
提供額外的串口、并口、CAN、RS-422/485或光纖通信接口，滿足復雜設備間或模塊間數據交互需求。
信號處理與適配
實現信號調理、隔離、放大、濾波等操作，保障主板處理的信號穩定有效。
定制用途
某些TEL設備特定工藝段中，此添加板可能作為“定制電路”平臺，連接專用傳感器或執行機構。
三、典型應用場景
設備控制系統升級或功能拓展
在原有主板不更換的情況下，增加更多外設連接能力或處理邏輯。
復雜I/O需求的場景
如多個傳感器輸入、電磁閥輸出等，無法在單塊主控板完成時，通過添加板實現補充。
設備模塊化組裝與維修
易于拆裝、更換和功能升級，提升系統的可維護性和擴展性。
英文資料：
TEL Tokyo Electron 1B80-002394-11 Add On Board is an expansion circuit board installed in the main control system or functional module of Tokyo Electronics (TEL) semiconductor equipment. It is used to enhance the functionality of existing motherboards, increase I/O interfaces, support specific signal processing or communication expansion, and is an important manifestation of device modular design.
1、 Basic Product Information
Project Content
Product Name: Add On Board
Product model 1B80-002394-11
Belonging to Tokyo Electron Ltd
Installation method: Plug in or stacked connection to the main control board or subsystem module
2、 Main functions
Function Expansion
Provide additional functions for the main control board or I/O control system, such as additional input/output channels, analog signal processing, temperature/pressure interfaces, optocoupler isolation, etc.
Expansion of Communication Interface
Provide additional serial, parallel, CAN, RS-422/485, or fiber optic communication interfaces to meet the data exchange needs between complex devices or modules.
Signal processing and adaptation
Implement signal conditioning, isolation, amplification, filtering and other operations to ensure the stability and effectiveness of the signals processed by the motherboard.
Customized use
In certain TEL equipment specific process segments, this add-on board may serve as a "custom circuit" platform, connecting dedicated sensors or actuators.
3、 Typical application scenarios
Equipment control system upgrade or functional expansion
Add more peripheral connectivity or processing logic without replacing the original motherboard.
Scenarios with complex I/O requirements
When multiple sensor inputs, solenoid valve outputs, etc. cannot be completed on a single main control board, supplementation can be achieved by adding boards.
Modular assembly and maintenance of equipment
Easy to disassemble, replace, and upgrade functions, enhancing the maintainability and expandability of the system.
