MC68060 MPU
The MC68060 microprocessor is the main processor for the
MVME177. The superscalar MC68060 processor has:
? Two MC68040-compatible CPU integer cores
? MC68040-compatible floating point core
? Independent 8KB instruction and operand data caches
? MC68040-compatible paged memory management unit
? A bus controller
The processor is in a PGA socket. Its clock speed is 50 MHz (for the
-00x models), and 60 MHz (for the -01x models). Note that the local
processor bus runs at only half the processor speed. Refer to the
MC68060 user's manual for more information.
Flash Memory and EPROM
Flash Memory
The MVME177 includes four 28F008SA Flash memory devices. The
Flash devices provide 4MB of ROM at address $FF800000-
$FFBFFFFF. The Flash is organized as one 32-bit bank for 32-bit
code execution from the processor. The Flash could, for instance, be
used for the onboard debugger firmware (177Bug) which would be
downloaded from I/O resources such as:
? Ethernet
? SCSI
? A serial port, or
? The VMEbus
When Flash is used with EPROM, either the top or bottom 2MB of
Flash is available in the second 2MB of memory space after the
EPROM. Refer to Table 4-1 below. Because only 1M x 8-bit Flash chips are used, there is no userconfigured jumper selection block required to pick the Flash chip
size.
The memory map for the Flash devices is controlled by the
VMEchip2 ASIC. The 32-bit wide Flash can support:
? 8 bit
? 16 bit, and
? 32 bit access
Flash write protection is programmable through the VMEchip2
GPIO register. The address map location of Flash is at $000000
through $3FFFFF at local reset if the FLASHJP jumper (J8) is in,
providing for the all-Flash mode. In the mixed EPROM/Flash
mode, half of the Flash is accessable at addresses $200000 through
$3FFFFF, depending on the condition of the VMEchip2 GPIO2 bit.
Because the MVME177 uses 1M x 8-bit Flash memory devices and
EPROMs with no download ROM, the software programs the
VMEchip2 ROM0 and REV EROM bits properly so that the
Flash/EPROM appears at address $0 after powerup.
