DS200TCQCG1BFE模擬量輸入模塊
電壓：
5V至60VDC電流：0.001A至2A關斷狀態泄漏電流，最大值100uA，60VDC儀表套件規格（2）支持的校驗儀脈沖輸出功能從選定的雙通道對提供“良好脈沖”，以支持校驗儀應用。最多支持5個脈沖IOTA總線連接在一起。校準儀電氣特性開式發射器源極驅動器-參考系統接地開路電壓：22V短路電流限制：35mA脈沖數據保真度符合ISO 6551:1995規定的A級保真度注1：可選的交流繼電器（51190516-332）可替代提供的直流繼電器，以提供交流切斷信號。切斷時間延長至交流電源信號的一個線路周期。注2：需要MeterSuite應用注3：對于雙通道操作，最小可檢測脈沖寬度為10us。（雙流配置具有“內置”10us脈寬抑制功能）Experion Series-C輸入/輸出規范，EP03-490-520 21版本1.5霍尼韋爾專有2021 12月8。模擬輸出具有HART–CC-PAOH01功能模擬輸出（AO）模塊向執行器和記錄/指示設備提供高電平恒定電流。
顯著特點
?廣泛的自我診斷?可選冗余?支持HART，多變量儀表?多個調制解調器用于快速收集控制變量?安全狀態（FAILOPT）行為可按每個通道配置?輸出回讀和差異報警?非易燃輸出FAILOPC系列AO模塊支持按每個通道的FAILOPD參數。用戶可以將每個通道配置為保持最后一個值或設置為安全值。如果IOM設備電子設備發生故障，輸出將始終歸零，即安全狀態。開路檢測此C系列IO功能將能夠檢測并通過通道軟故障指示通知開路現場線。詳細規范–HART模擬輸出
參數規范輸入/輸出型號CC-PAOH01-帶HART IOTA型號CC-TAOX01的高電平模擬輸出，非冗余6“CC-TAOX11冗余12”CC-GAOX11非冗余12“CC-GAOX21非冗余6”輸出類型4-20 mA輸出通道16輸出紋波<100 mV
Voltage:
5V to 60VDC current: 0.001A to 2A off state leakage current, maximum 100uA, 60VDC instrument kit specification (2) The supported calibrator pulse output function provides "good pulse" from the selected dual channel pair to support the calibrator application. Up to 5 pulse IOTA buses can be connected together. Electrical characteristics of the calibrator Open transmitter source driver Reference system Ground open circuit voltage: 22V Short circuit current limit: 35mA Pulse data fidelity in accordance with ISO 6551:1995 Class A Fidelity Note 1: The optional AC relay (51190516-332) can replace the DC relay provided to provide an AC cut-off signal. The cut-off time is extended to one line cycle of the AC power signal. Note 2: MeterSuite application is required Note 3: For dual channel operation, the minimum detectable pulse width is 10us. (Dual stream configuration has "built-in" 10us pulse width suppression function) Experion Series-C input/output specification, EP03-490-520 21 version 1.5 Honeywell proprietary December 8, 2021. Analog output with HART – CC-PAOH01 function Analog output (AO) module provides high level constant current to actuator and recording/indicating equipment.
Salient features
? Extensive self diagnosis ? Optional redundancy ? Support HART, multivariable instruments ? Multiple modems for fast collection of control variables ? Safe state (FAILOPT) behavior can be configured per channel ? Output readback and differential alarm ? Non incendive output FAILOPC series AO modules support FAILOPD parameters per channel. You can configure each channel to hold the last value or set it as a safe value. If the electronic device of the IOM device fails, the output will always return to zero, that is, the safe state. Open circuit detection This C series IO function will be able to detect and notify open circuit field lines through channel soft fault indication. Detail Specification – HART Analog Output
Parameter specification Input/output model CC-PAOH01 High level analog output with HART IOTA model CC-TAOX01, non redundant 6 "CC-TAOX11 redundant 12" CC-GAOX11 non redundant 12 "CC-GAOX21 non redundant 6" output type 4-20 mA output channel 16 output ripple<100 mV
