DSCL110A控制模塊ABB
使用說明及參數
說明57520001-BC是一款完全可編程的Native BACnet?樓宇控制器，可使用以太網上的BACnet IP和BACnet在雙絞線以太網10 BaseT上進行通信，或使用BACnet MS/TP協議在RS-485 LAN上進行通信。57520001-BC專為具有中等本地I/O要求的廣泛應用而設計。它還支持BACstat?和其他Delta LINKnet設備。應用57520001-BC適用于控制具有中等I/O要求的各種成套裝置和設備，如多室再熱閥或小型空氣處理裝置、鍋爐和冷卻器。完全可編程的57520001-BC可以通過創建和修改BACnet對象和GCL+程序來定制特定應用。功能在GCL+超級電容器中完全可編程，用于實時時鐘和SRAM備份（無需維護）支持LINKnet上的12個BACstat網絡傳感器，用于室內傳感和控制，或LINKnet中的2個Delta現場模塊，
用于I/O擴展每個模擬輸出的執行器電源端子（24 VAC）（可由內部或輔助變壓器供電）固件升級和數據庫加載/通過網絡保存可選的Modbus?RTU現場升級，帶硬件鍵服務端口螺釘或DIN導軌安裝LED指示燈，用于輸出、電源、，CPU和SCAN狀態規格BACnet設備配置文件BACnet樓宇控制器（B-BC）輸入11個通用輸入（10位），支持：0-5 VDC 0-10 VDC 10 kΩ熱敏電阻干觸點（使用10 kΩ熱敏電阻跳線設置）4-20 mA輸出8個模擬輸出（0-10 VDC）設備尋址設置，通過DIP開關和跳線，或軟件設置連接器可拆卸螺釘型端子連接器布線類別2/SELV
Instructions and parameters
Description: 57520001-BC is a fully programmable Native BACnet ? Building controller can use BACnet IP and BACnet on Ethernet to communicate on twisted pair Ethernet 10 BaseT, or BACnet MS/TP protocol to communicate on RS-485 LAN. The 57520001-BC is designed for a wide range of applications with moderate local I/O requirements. It also supports BACstat ? And other Delta LINKnet devices. Application 57520001-BC is suitable for controlling various complete sets of devices and equipment with medium I/O requirements, such as multi chamber reheat valves or small air handling devices, boilers and coolers. The fully programmable 57520001-BC can customize specific applications by creating and modifying BACnet objects and GCL+programs. The function is fully programmable in GCL+supercapacitor, used for real-time clock and SRAM backup (maintenance free) Support 12 BACstat network sensors on LINKnet, used for indoor sensing and control, or 2 Delta field modules in LINKnet,
Actuator power terminal (24 VAC) for I/O expansion of each analog output (can be powered by internal or auxiliary transformer) Firmware upgrade and database loading/optional Modbus saved via network ? RTU field upgrade, with hardware key service port screw or DIN rail mounted LED indicator, for output, power, CPU and SCAN status specifications, BACnet device configuration file, BACnet building controller (B-BC), input 11 universal inputs (10 bits), support: 0-5 VDC 0-10 VDC 10 k Ω thermistor dry contact (set with 10 k Ω thermistor jumper), 4-20 mA output, 8 analog outputs (0-10 VDC), device addressing setting, Connector detachable screw type terminal connector wiring category 2/SELV via DIP switches and jumpers, or software settings
