57310001-KY
安裝位置任何裝配說明排零間距標準
請注意，顯示的數據是根據我們的在線目錄生成的。 我們的通用下載使用條款有效VARIOFACE模塊，帶刀式斷開端子板，用于：-S800 I/O輸入模塊，模塊寬度：126.5 mm產品具有八個帶刀片斷開的正極接線板（TU810/P）八個帶刀斷開的負極接線板（TU810）一個帶每個通道刀片斷開（TU830）的正極和負極接線板關鍵商業數據包裝第一單元每件重量（不包括包裝）331.6 GRM定制關稅編號85369010原產國德國技術數據尺寸寬度126.5 mm高度90 mm深度61 mm環境條件環境溫度（操作）-20°C…50°C環境溫度（存儲/運輸）-20°F…70°C一般標稱電壓UN 50 V AC/DC每個支路的最大載流容量2 A電壓的最大總電流第2/4頁接口模塊-FLKM-D25 SUB/KDS3-MT/TU810/P-2304539技術數據一般狀態顯示無測試電壓800 V（50 Hz，1分鐘）
測試電壓觸點/觸點0.8 kV AC安裝位置任何裝配說明排零間距標準/法規DIN EN 50178 IEC 62103污染度2浪涌電壓II類額定浪涌電壓1.4 kV連接數據1連接名稱現場水平連接方法螺紋連接帶斷開刀導體橫截面最小為0.2 mm2導體橫截面實心最大為4 mm2導線橫截面絞合最小為0.2 m2導體截面絞合最大為2.5 mm2最小為24導體橫截面AWG/kcmil最大為12剝離長度8 mm螺紋M3連接數據2連接名稱控制系統級別連接方法D-SUB插座條位置數量25支持的控制器控制器ABB S800 I/O-合適的I/O卡DI810 DI811 DI830 DI831 DI840 DO814 AI810 AI820
Zero spacing standard for any assembly instructions at the installation position
Please note that the data displayed is generated from our online catalog. Our general download terms of use are valid VARIOFACE modules with knife type disconnecting terminal blocks for: - S800 I/O input modules, Module width: 126.5 mm The product has eight positive terminal blocks (TU810/P) with blade disconnections, eight negative terminal blocks (TU810) with blade disconnections, one positive and negative terminal blocks with blade disconnections (TU830) for each channel. Key business data package. Weight of each unit (excluding package) 331.6 GRM custom tariff No. 85369010 Country of Origin Germany Technical data Size width 126.5 mm Height 90 mm Depth 61 mm Environmental conditions Ambient temperature (operation) - 20 ° C... 50 ° C Ambient temperature (storage/transportation) - 20 ° F... 70 ° C General nominal voltage UN 50 V AC/DC Maximum current carrying capacity of each branch 2A Maximum total current of voltage Page 2 of 4 Interface module FLKM-D25 SUB/KDS3-MT/TU810/P-2304539 General status of technical data shows no test voltage 800 V (50 Hz, 1 minute)
Test voltage contact/contact 0.8 kV AC Installation position Any assembly instructions Zero spacing standard/regulation DIN EN 50178 IEC 62103 Pollution degree 2 Surge voltage Class II Rated surge voltage 1.4 kV Connection data 1 Connection name Field horizontal connection method Screw connection with disconnecting knife Conductor cross-section minimum 0.2 mm 2 Conductor cross-section solid max. 4 mm 2 Conductor cross-section stranding 0.2 m minimum 2 Conductor section stranding up to 2.5 mm 2 Minimum 24 conductor cross-section AWG/kcmil Maximum 12 Stripping length 8 mm Thread M3 Connection data 2 Connection name Control system level Connection method D-SUB Number of socket bar positions 25 Supported controller controller ABB S800 I/O - Suitable I/O card DI810 DI811 DI830 DI831 DI840 DO814 AI810 AI820
