5712289-A備件模塊
可編程的超光效果
可以以多種方式使用：?作為傳統的開/關輸出，它們可以驅動駕駛室燈、標志燈、號碼牌、小型繼電器或其他電子電路的額外燈泡。?作為火星燈，它們可以用來模擬在南太平洋、聯合太平洋和鎳板公路等鐵路使用的現代蒸汽機前面發現的著名警示燈輸出也可以設置為模擬來自火箱的閃爍輝光。最好在機車的火箱區域下面安裝一個橙色或紅色的燈第二種版本的火箱閃爍效果可用，僅當火箱門打開的聲音被激活時才會打開，當門“關閉”時才會關閉。這種效果的燈最好安裝在駕駛室中，位于部分打開的火箱門細節后面。
獨立編程
每個Hyperlight輸出都可以獨立編程，因此可以將一個燈泡用作火星燈，另一個燈泡用于火箱。功能輸出也可用于控制其他電氣設備，如煙霧發生器，但必須小心，這些設備不會超過輸出的額定電流（100 mA），在這種情況下，需要添加繼電器或其他低電流開關設備。電感負載（如繼電器線圈）可能需要箝位二極管。您還必須注意，每個燈的總電流消耗和機車的失速電流不會超過解碼器的額定電流。最后，您需要決定是否將投標者和機車之間的電氣連接硬接線或使用可插拔連接器。使用連接器將使您能夠分離發動機并進行存放，并使噴漆和維修更容易，但在較小的型號中可能會很難看，還可能會在重新組裝過程中反轉連接器，從而意外損壞解碼器。對解碼器進行硬接線將防止這種可能性，但會使投標分離變得困難。
Programmable hyperlight effect
It can be used in many ways: ? As a traditional on/off output, they can drive cab lights, marker lights, number plates, small relays or additional bulbs of other electronic circuits. ? As Martian lights, they can be used to simulate the output of famous warning lights found in front of modern steam engines used in railways such as the South Pacific, the United Pacific and the Nickel Plate Highway, and can also be set to simulate the flashing glow from the firebox. It is better to install an orange or red light under the fire box area of the locomotive. The second version of the fire box flashing effect is available. It will only open when the sound of the fire box door opening is activated, and will only close when the door is "closed". A lamp of this effect is preferably mounted in the cab, behind the details of the partially opened firebox door.
Independent programming
Each Hyperlight output can be programmed independently, so you can use one bulb as a Mars lamp and the other bulb as a firebox. The functional output can also be used to control other electrical devices, such as smoke and fog generators, but care must be taken that these devices do not exceed the rated output current (100 mA), in which case relays or other low current switching devices need to be added. Inductive loads such as relay coils may require clamping diodes. You must also note that the total current consumption of each lamp and the stall current of the locomotive will not exceed the rated current of the decoder. Finally, you need to decide whether to hardwire the electrical connection between the bidder and the locomotive or use pluggable connectors. Using the connector will enable you to separate the engine and store it, and make painting and maintenance easier, but it may be ugly in smaller models, and it may also reverse the connector during reassembly, thus accidentally damaging the decoder. Hardwiring the decoder will prevent this possibility, but will make bid separation difficult.
