標準軟盤驅動器控制器
集成外設3BHE013940R0002集成了國家半導體超級I/O（SIO）芯片。SIO為3BHE013940R0002提供標準軟盤驅動器控制器、兩個16550 UART兼容串行端口、鍵盤和鼠標端口以及用于系統監控功能的通用I/O。兩個串行端口信號都可從前面板獲得。軟盤信號可通過VME背板連接器獲得，并可通過適當?shù)霓D(zhuǎn)換實用程序板（VMIACC-0562）訪問。IDE接口由Intel I/O控制器集線器（ICH2）芯片提供。IDE接口支持兩個通道，即主通道和輔助通道。輔助通道在板上路由到可選的緊湊型閃存插槽。主通道從VME背板路由至VMIACC-0562轉換實用程序板，該板終止于標準的40針接頭。此通道可以支持兩個驅動器，一個主驅動器和一個從驅動器。3BHE013940R0002上的IDE接口支持ATA-33、ATA-66和ATA-100驅動器，并根據使用的驅動器類型自動確定正確的操作模式。為了在ATA-100模式下正常工作，必須使用特殊的80芯電纜，而不是標準的40芯電纜。此電纜通?？蓮腁TA-100驅動器制造商處獲得。
以太網控制器雙網絡功能
以太網控制器雙網絡功能由外部Intel 82559ER以太網控制器和Intel ICH2芯片內部的MAC提供。兩個以太網控制器都是基于PCI的，并且是軟件可配置的。3BHE013940R0002支持雙10BaseT和100BaseTx以太網。10BaseT基于10BaseT標準的網絡使用非屏蔽雙絞線電纜，通過允許使用現有電話線路和連接器，為網絡提供了經濟的解決方案。RJ-45連接器與10BaseT標準一起使用。10BaseT的最大長度為100米。100BaseTx 3BHE013940R0002還支持100BaseTx以太網。基于100BaseTx標準的網絡使用非屏蔽雙絞線電纜和RJ-45連接器。100BaseTx的最大長度為100米。
Standard Floppy Drive Controller
The integrated peripheral 3BHE013940R0002 integrates the National Semiconductor Super I/O (SIO) chip. SIO provides 3BHE013940R0002 with a standard floppy disk drive controller, two 16550 UART compatible serial ports, keyboard and mouse ports, and general I/O for system monitoring functions. Both serial port signals are available from the front panel. The floppy disk signal is available through the VME backplane connector and is accessed through the appropriate conversion utility board (VMIACC-0562). The IDE interface is provided by the Intel I/O Controller Hub (ICH2) chip. The IDE interface supports two channels, namely the primary channel and the secondary channel. The secondary channel is routed on the board to the optional compact flash slot. The primary channel is routed from the VME backplane to the VMIACC-0562 conversion utility board, which terminates at the standard 40 pin connector. This channel can support two drives, one master drive and one slave drive. The IDE interface on 3BHE013940R0002 supports ATA-33, ATA-66, and ATA-100 drives, and automatically determines the correct operation mode according to the drive type used. In order to work properly in the ATA-100 mode, a special 80 core cable must be used instead of the standard 40 core cable. This cable is usually available from the ATA-100 drive manufacturer.
Dual network function of Ethernet controller
The dual network function of Ethernet controller is provided by the external Intel 82559ER Ethernet controller and the internal MAC of Intel ICH2 chip. Both Ethernet controllers are PCI based and software configurable. 3BHE013940R0002 supports dual 10BaseT and 100BaseTx Ethernet. 10BaseT network based on 10BaseT standard uses unshielded twisted pair cable, which provides an economical solution for the network by allowing the use of existing telephone lines and connectors. RJ-45 connector is used with 10BaseT standard. The maximum length of 10BaseT is 100 meters. 100BaseTx 3BHE013940R0002 also supports 100BaseTx Ethernet. The network based on 100BaseTx standard uses unshielded twisted pair cables and RJ-45 connectors. The maximum length of 100BaseTx is 100 meters.
產品優勢
1：國外專業的供貨渠道，具有價格優勢
2：產品質量保證，讓您售后無憂
3：全國快遞包郵
4：一對一服務
公司主營范圍簡介
PLC可編程控制器模塊，DCS卡件，ESD系統卡件，振動監測系統卡件，汽輪機控制系統模塊，燃氣發電機備件等，優勢品牌：Allen Bradley、BentlyNevada、ABB、Emerson Ovation、Honeywell DCS、Rockwell ICS Triplex、FOXBORO、Schneider PLC、GE Fanuc、Motorola、HIMA、TRICONEX、Prosoft等各種進口工業零部件、歐美進口模塊。
產品廣泛應用于冶金、石油天然氣、玻璃制造業、鋁業、石油化工、煤礦、造紙印刷、紡織印染、機械、電子制造、汽車制造、塑膠機械、電力、水利、水處理/環保、鍋爐供暖、能源、輸配電等等
