注意事項
ABB程序員應該注意，英特爾處理器有一個完全獨立于內存總線的I/O總線。本手冊已盡一切努力澄清這一點，通過在I/O地址前面加上前綴來參考I/O空間中的寄存器和邏輯實體。因此，寄存器“I/O$140”與寄存器“$140”不同，因?yàn)楹笳咴趦?nèi)存總線上，而前者在I/O總線上。?英特爾程序員應注意，本手冊中列出的地址使用線性“平面內存”模型，而不是與英特爾實模式編程相關的舊段：偏移模型。因此，在本手冊中，位于段：偏移地址C000:0的ROM芯片將被列為地址$C0000。為了參考，這里有一些快速轉換公式：段：偏移到線性地址線性地址=（段×16）+偏移線性地址到段：偏移段=（（線性地址÷65536）? 余數）×4096偏移量=余數×65536其中余數=（線性地址÷65536）的小數部分注意，有許多可能的段：單個位置的偏移地址。上面的公式將提供一個唯一的段：偏移地址，將段強制到一個偶數64 KB的邊界，例如$C000、$E000等。使用此公式時，請確保正確舍入偏移計算！
使用說明
UUD148AE01的硬件跳線設置、連接器說明、安裝、系統設置和操作。開箱程序應遵守裝運集裝箱中的任何預防措施。所有物品都應仔細拆開包裝，并徹底檢查在裝運期間可能發生的損壞。應檢查電路板是否有損壞的組件、損壞的印刷電路板、熱損壞和其他可見污染。因運輸損壞引起的所有索賠應向承運人提交，并向VMIC客戶服務部門發送完整的報告，同時請求就損壞物品的處置提出建議。警告：VMIC產品上組裝的一些組件可能對靜電放電敏感，并且在受到高能靜電場的電路板上可能會發生損壞。當電路板放置在工作臺上進行配置等時，建議在電路板下方插入導電材料，以提供導電分流。未使用的板應存放在裝運時的相同保護箱中。
matters needing attention
ABB programmers should note that Intel processors have an I/O bus that is completely independent of the memory bus. This manual has made every effort to clarify this by prefixing the I/O address to refer to registers and logical entities in the I/O space. Therefore, register "I/O $140" is different from register "$140" because the latter is on the memory bus and the former is on the I/O bus. ? Intel programmers should note that the addresses listed in this manual use the linear "plane memory" model, not the old segment related to Intel real mode programming: the offset model. Therefore, in this manual, the ROM chip located at segment: offset address C000:0 will be listed as address $C0000. For reference, here are some fast conversion formulas: segment: offset to linear address linear address=(segment × 16) +Offset linear address to segment: Offset segment=((linear address ÷ 65536) ? remainder) × 4096 offset=remainder × The decimal part of 65536 where the remainder=(linear address ÷ 65536) Note that there are many possible segments: offset address of a single position. The above formula will provide a unique segment: offset address, and force the segment to an even 64 KB boundary, such as $C000, $E000, etc. When using this formula, please ensure that the offset calculation is rounded correctly!
instructions
Hardware jumper settings, connector descriptions, installation, system settings, and operation of UUD148AE01. Unpacking procedures should follow any precautions in the shipping container. All items shall be carefully unpacked and thoroughly inspected for possible damage during shipment. The circuit board should be checked for damaged components, damaged printed circuit boards, thermal damage and other visible contamination. All claims arising from transportation damage shall be submitted to the carrier, and a complete report shall be sent to VMIC customer service department, and suggestions on the disposal of damaged items shall be requested. Warning: Some components assembled on VMIC products may be sensitive to electrostatic discharge and may be damaged on circuit boards subject to high energy electrostatic fields. When the circuit board is placed on the workbench for configuration, it is recommended to insert conductive materials under the circuit board to provide conductive shunt. Unused plates shall be stored in the same protective box as shipped.
產品優勢
1：國外專業的供貨渠道，具有價格優勢
2：產品質量保證，讓您售后無憂
3：全國快遞包郵
4：一對一服務
公司主營范圍簡介
PLC可編程控制器模塊，DCS卡件，ESD系統卡件，振動監測系統卡件，汽輪機控制系統模塊，燃?xì)獍l(fā)電機備件等，優勢品牌：Allen Bradley、BentlyNevada、ABB、Emerson Ovation、Honeywell DCS、Rockwell ICS Triplex、FOXBORO、Schneider PLC、GE Fanuc、Motorola、HIMA、TRICONEX、Prosoft等各種進口工業零部件、歐美進口模塊。
產品廣泛應用于冶金、石油天然氣、玻璃制造業、鋁業、石油化工、煤礦、造紙印刷、紡織印染、機械、電子制造、汽車制造、塑膠機械、電力、水利、水處理/環保、鍋爐供暖、能源、輸配電等等
