功利用率的提高，關鍵點在于如何有效的對IGBT單元進行合理和有效的散熱。
功率單元在使用兩個FF450R17ME4模塊達到66%利用率的額定工況時，IGBT輸出頻率50Hz，開關頻率650Hz，功率因素0.9，單元輸出電流為297A，單個IGBT芯片損耗為78.7W，單個Diode芯片損耗為23.4W。
參考業內針對過載方面的標準，均為每10min內可允許120% 過載，過載時間為持續1min。按1.2倍過載，單元輸出電流為356.4A，單個IGBT芯片損耗為102W，單個Diode芯片損耗為28.9W。
單個IGBT和Diode的封裝熱阻和耐受溫度
單個IGBT和Diode的封裝熱阻和耐受溫度
圖3-單個IGBT和Diode的封裝熱阻和耐受溫度
（3）熱管散熱器仿真設計
散熱器的材質為AL1060，翅片厚度1.2mm，齒間距2.5mm，散熱器整體尺寸為330mm（L）*240mm（W）*93mm（H），熱管采用直徑為9mm的熱管，熱管和散熱器通過Hi-Connector工藝進行緊配，如圖4所示。
仿真模型詳細建模散熱器、熱管及IGBT內部封裝，邊界條件為散熱器出風口平均風速5m/s，環境溫度40℃，海拔為1000m以下。
散熱器仿真模型
散熱器仿真模型
圖4-散熱器仿真模型
（4）額定穩態仿真結果
在IGBT穩態運行工況下，環境溫度40℃，進風風速5m/s，IGBT芯片最高Tj=94.6℃，最高Tc=86.7℃，散熱器壓降197Pa。IGBT芯片結溫均小于工作允許的結溫Tj=150℃。
IGBT銅基板表面最高溫度Tc
IGBT銅基板表面最高溫度Tc
圖5- IGBT銅基板表面最高溫度Tc
IGBT芯片最高溫度Tj
IGBT芯片最高溫度Tj
圖6- IGBT芯片最高溫度Tj
