The voltage developed in the secondary of the sensing transformer(s)
and the voltage developed in the secondary of T2 add vectorially. This
action provides a voltage to the sensing diodes that is the vector sum of
the stepped down sensing voltage and the parallel current transformer
signal through T2. The sensing recti? er dc output is ? ltered and applied
to the error detector and underfrequency limit.
When a resistive (unity power factor) load is connected to the generator,
the voltage that appears across the droop potentiometer leads the sensing
voltage by 90 degrees, and the vector sum of the two voltages is nearly
the same as the original sensing voltage; consequently, almost no change
occurs in generator output voltage.
When lagging power factor (inductive) load is connected to the
generator, the voltage across the droop potentiometer becomes more
in phase with the sensing voltage, and the combined vectors of the two
voltages result in a larger voltage being applied to the sensing recti? ers.
Since the action of the regulator is to maintain a constant voltage at the
sensing recti? ers, the regulator reacts by decreasing the generator output
voltage.
When a leading power factor (capacitive) load is connected to the
generator, the voltage across the droop potentiometer becomes out of
phase with the sensing voltage, and the combined vectors of the two
voltages result in a smaller voltage being applied to the sensing recti? ers.
Then the regulator reacts by increasing the generator voltage.During parallel operation of two or more generators interconnected
for reactive voltage droop, if ? eld excitation on one of the generators
becomes excessive and causes a circulating current to ? ow between the
generators, the circulating current will appear as an inductive load to the
generator with excessive excitation and a capacitive load to the other
generator(s). The parallel components R4 and T2 will cause the voltage
regulator of the generator with excessive ? eld excitation to decrease the
generator voltage while the voltage regulators of the other generator(s)
will increase the generator voltage.
Sensing circuit during parallel generator operation in parallel crosscurrent compensation mode: Parallel cross-current compensation
allows two or more paralleled generators to share inductive reactive loads
with no droop or decrease in the generator system output voltage when
the line currents are proportional and in phase. This is accomplished by
the action and circuitry described previously for parallel reactive voltage
droop compensation and the interconnection of the current transformer
secondaries in a closed series loop. Circulating currents cause the system
to react as described previously for parallel voltage droop compensation
