BENTLY 125840-02監測器模塊
?脈沖發生器旋鈕-旋轉脈沖發生器以改變數字顯示中的值（例如，設定點、閥門或其他配置用于正常操作員顯示變化（例如比率、偏差）的變量。脈沖發生器旋鈕也用于：配置以更改字母數字顯示中的值。
包括加速器。將旋鈕旋轉得越快，顯示參數的變化率越大。較大的值變化則需要較少的旋鈕旋轉。
?V條形圖-該水平條形圖顯示有源回路中控制器輸出的縮放范圍。這個
輸出/閥門信號顯示為量程值的%。工程單位的數值可通過以下方式查看：
按下D按鈕以顯示點V參數（例如TC2053.V）。9.2配置模式配置按鈕位于面板下四分之一的翻轉門后面。注意其中許多按鈕用于正常操作模式和配置模式，如下所述。
?進入/退出配置-當工作站處于在正常操作模式下，或在配置模式。
?報警/降壓-具有雙重用途。
在正常情況下操作模式下，按下按鈕將滾動瀏覽報警
配置參數（如果報警功能塊已在有源環路中配置。報警設置顯示在中工程單位和范圍值的百分比也將顯示在
通過閃爍等于范圍%的單個段，設定點條形圖價值如果滿足安全許可，參數也可以是改變。有關的詳細信息，請參見報警功能塊說明參數。按ENTER/EXIT CONFIG（進入/退出配置）按鈕返回聯機顯示。在配置模式下，此按鈕將跳轉到下一個配置級別。請參閱本節的配置概述部分
有關配置模式典型級別的詳細信息，請參閱手冊。
?調諧/升壓-具有雙重目的。正常運行時模式下，按下按鈕將滾動控制器調諧
參數并允許激活自動調諧算法，如果為環路控制器配置。如果滿足安全許可，則參數也可以改變。按下進入/退出配置按鈕以返回到聯機顯示。
當處于配置模式時，此按鈕將升級到下一個配置級別。
?標簽/<----具有雙重用途。在正常操作模式下，按下按鈕將滾動
字母數字顯示中活動循環的完整標記名。標簽將一次滾動一個字符
從右側開始（例如-------T，--TI，--TIC）。
? Pulser Knob - rotate the Pulser to change the value in the numeric display (e.g. Setpoint, Valve, or other
variable configured for normal operator display changes such as Ratio, Bias). The Pulser knob is also used in
configuration to change values in the alphanumeric display.
An accelerator is included. Turning the knob faster multiplies the rate of change of the displayed parameter.
Large value changes then require fewer knob rotations.
? V Bargraph - this horizontal bargraph displays the scaled range of the controller output in the Active Loop. The
output/valve signal is shown as the % of range value. The value in engineering units can be viewed by
pressing the D button to display the dot V parameter (e.g. TC2053.V). 9.2 CONFIGURATION MODE
Configuration pushbuttons are located behind the flip-down door on the lower quarter of the faceplate. Note that
many of these buttons are used in both the normal operation mode and configuration mode, as described below.
? ENTER/EXIT CONF - press to enter configuration when the station is
in the normal operation mode or to exit configuration when in the
configuration mode.
? ALARM/STEP DOWN - has a dual purpose. When in the normal
operation mode, pressing the button will scroll through the alarm
configuration parameters if the ALARM function block has been
configured in the Active Loop. The alarm setting is displayed in
engineering units and the % of range value will also be displayed on the
setpoint bargraph by flashing a single segment equal to the % of range
value. If security clearance is satisfied, the parameters can also be
changed. See the ALARM function block description for details on the
parameters. Press the ENTER/EXIT CONFIG button to return to the online displays.
When in the configuration mode, this button will step down to the next
configuration level. See the Configuration Overview section of this
manual for details on typical levels of the configuration mode.
? TUNE/STEP UP - has a dual purpose. When in the normal operation
mode, pressing the button will scroll through the controller tuning
parameters and allow activating the AUTOTUNE algorithm, if
configured for the loop controller. If security clearance is satisfied, the
parameters can also be changed. Press the ENTER/EXIT CONFIG button
to return to the on-line displays.
When in the configuration mode, this button will step up to the next configuration level.
? TAG/<--- - has a dual purpose. When in the normal operation mode, pressing the button will scroll the
complete tag name of the Active Loop in the alphanumeric display. The tag will scroll one character at a time
starting on the right (e.g. -------T, -----TI, ----TIC).
