System 57控制器安裝程序概述如下：
如下所示：
a、 打開包裝并檢查設備。
b、 確定合適的位置并檢查布線要求。
c、 確認電源要求。
d、 根據需要安裝機柜、19“安裝框架或面板切口。
e、 將系統57機架安裝到機柜、19“安裝框架或面板切口。
f、 將傳感器和導線安裝回系統57。
g、 檢查并在必要時重新配置單通道控制卡。
h、 將傳感器連接至現場接口/繼電器卡接線板。
i、 連接現場接口/繼電器卡接線板的輸出。
j、 將電源連接到直流輸入卡。
安裝完成后，執行調試程序
如第5章所述。
本章以下各節詳細解釋了安裝操作。開箱
收到時：a、 仔細打開設備包裝，遵守打印的任何說明在包裝上或包含在包裝中。
b、 檢查內容物在運輸過程中是否損壞，并檢查包裝注意缺陷。
c、 找到裝置隨附的配置表并確認每個通道卡類型和設置與建議的傳感器。
位置控制系統必須安裝在安全區域，如控制器或設備室，遠離熱源，具有足夠的
通風良好，不受天氣影響。
有兩種不同的System 57機架配置可容納：前或后現場接線入口。每個配置在中都可用半寬或全寬19英寸。三種最常見的安裝方法是：
a、 19“安裝架系統57 19英寸6U前和3U后檢修機架兼容
采用標準19英寸（483mm）子架格式，因此安裝在任何合適的19”安裝框架中。
b、 內閣壁掛式機柜有兩種尺寸，可容納：19英寸和半19英寸6U前檢修機架組件。
c、 面板或者，所有機架都適合直接安裝到面板中開孔。
可提供19英寸和半19英寸1U格式的電源裝置，
用于使用交流輸入電源的應用。它是建議將電源裝置直接安裝在上方系統57機架。
INTRODUCTION
A summary of the System 57 controller installation procedures is
shown below:
a. Unpack and check the equipment.
b. Identify a suitable location and check the cabling requirements.
c. Confirm the power supply requirements.
d. Install the Cabinet, 19" Mounting Frame or Panel Cutout as required.
e. Fit the System 57 rack into the Cabinet, 19" Mounting Frame or
Panel Cutout.
f. Install the sensors and wire back to the System 57.
g. Check, and if necessary reconfigure, the Single Channel Control
Cards.
h. Wire the sensors to the Field Interface/Relay Card terminal blocks.
i. Wire the outputs from Field Interface/ Relay Card terminal blocks.
j. Wire the power supply to the DC Input Card.
After installation is complete perform the commissioning procedures
outlined in Chapter 5.
The following sections of this chapter provide a detailed explanation of
the installation operations.
UNPACKING
On receipt:
a. Carefully unpack the equipment observing any instructions printed
on or contained in the packaging.
b. Check the contents for transit damage and against the packing
note for deficiencies.
c. Locate the configuration sheet supplied with the unit and confirm
that each channel card type and settings are compatible with the
proposed sensors.
LOCATION
The control system must be installed in a safe area such as a control
or equipment room, away from sources of heat, with adequate
ventilation and protected from the weather.
There are two different System 57 rack configurations to accommodate
either front or rear field wiring entry. Each configuration is available in
half or full 19" width. The three most common mounting methods are:
a. 19" Mounting Frame
The System 57 19" 6U front and 3U rear access racks are compatible
with the standard 19" (483mm) sub-rack format and may therefore
be fitted into any suitable 19" mounting frame.
b. Cabinet
Wall mounting cabinets are available in two sizes to accommodate
the 19" and half 19" 6U front access rack assemblies.
c. Panel
Alternatively all the racks are suitable for fitting directly into a panel
cutout aperture.
Power supply units are available, in both 19" and half 19" 1U formats,
for applications where an ac input power source is to be used. It is
recommended that the power supply units are mounted directly above
the System 57 rack.
