產品必須符合標準X、防護等級Y甚至2MOPP，因?yàn)殡娫匆驯粵Q定用在最近推出的呼吸機上。最重要的是，開發人員還需要考慮MTBF值。想象一下患者連上了呼吸機，而電源突然出現故障…… 這當然要不惜一切代價來避免！因此，開發人員需要知道電源在沒有維護的情況下可以安全工作多長時間。這篇關于RECOM的RACM1200-V的文章可以回答其中一些問題。
RECOM認為最安全的選擇是唯一的選擇，在設計RACM1200-V時就牢記了這一點，電源也必須通過所有必要的認證。
3BHB003230R0101模塊，5SHX1445H0001配置手冊RACM1200-V樹立了對緊湊定義的新標準，涵蓋極寬的功率范圍，無風扇冷卻也能可靠地工作。特殊的基板確保有效散熱并提供高達1000W的連續輸出功率。RACM1200-V帶有兩個額外的輸出因此不像一些應用需要額外電源，并提供12V可調系統風扇輸出和5V/1A待機輸出。
由于電源電壓和輸出電壓之間有4kVAC隔離電壓，因此RACM1200-V幾乎可用在需要電源的所有地方，例如充電器、LED照明系統、激光設備、分析儀器、高頻器件、機器人、醫療床椅，以及與患者直接接觸的醫療設備。RECOM可為設計人員提供符合規格需求的電源。
雖然RACM1200-V通過IEC 60601-1認證，但不能保證要安裝它的設備也符合標準。然而使用認證電源是滿足標準的前提之一，除了確實能夠降低開發成本還可以加快最終產品的認證過程。
RACM1200-V提供符合2MOPP認證的（MOPP=患者保護措施）絕緣和最小漏電流，這意味著它符合醫療設備的患者安全標準。
信號輸出和5V輸出與電源電壓之間的隔離為1.5kVAC。
RACM1200-V系列具有集成EMC濾波器，可以輕松滿足EN 55032:2015 Class B對輻射干擾和線路干擾的要求。新型RECOM電源符合所有工業應用、IT產品和醫療設備相關的國際安全標準。
RACM1200-V的輸入電壓范圍為85 VAC至264 VAC，允許高達1000W的連續輸出。采用40mm高的金屬外殼，封裝面積僅102mm x 229mm，可接觸冷卻。輸出功率可達1200W并維持10秒。若要1200W連續輸出，電源必須配備風扇同時確保有2.5m/s的空氣流動。這就是為什么RACM1200-V也配備了控制輔助輸出以進行溫度管理。輸出功率：40°C環境溫度和230V輸入電壓的輸出功率為1000W；使用風扇或短峰值負載可達1200W。
