3BHB004791R0101配置手冊,ABB勵磁模塊
程序塊最多512個程序塊。塊的最大大小為128KB。
%I和%Q:32Kbits用于離散%AI和%AQ：最多可配置32Kwords%W： 可配置到最大可用用戶RAM托管內存（符號和輸入/輸出變量組合）：可配置高達10 MB以太網接口規范基于Web的數據監控多達16個Web服務器和FTP連接（組合）此版本的重要產品信息以太網固件版本6.20增加了SNTP對本地時區和夏令時的支持。
3BHB004791R0101配置手冊有關詳細信息，請參閱第5頁的“固件版本6.20中的新以太網功能和增強”。對于在中解決的問題此版本，請參閱第16頁的“在固件版本6.20中解決的以太網問題”。
硬件版本-Jx更正硬件ID，以便在與智能電池一起使用時啟用低電池檢測。重要提示：建議用戶將station manager密碼更改為默認密碼以外的密碼
暗語當station manager密碼設置為時，將禁用對遠程station manager的訪問默認密碼。
GE Intelligent Platform建議禁用未使用的FTP服務器和/或Web服務器連接。對于詳見第19頁。更新CPE030和CPE040可以使用Winloader固件現場升級到CPU版本6.75和以太網版本6.20升級實用程序和以下升級工具包之一。LREAL數據類型支持需要5.50或更高版本的工具包。
當PACSystems CPU運行時，需要C Toolkit Release 5.00 Build 16C1或更高版本包含固件版本5.00或更高版本。注意：使用早于5.00 Build 16C1的C Toolkit版本構建的C塊必須使用更新的工具包版本重新編譯，以便與CPU固件一起使用5.00或更高版本。
Series 90 Toolkit（IC641SWP709/719）與PACSystems不兼容。PACSystems RX7i支持90-70系列擴展機架。PACSystems RX7i CPU和RX7i以太網模塊不在90-70系列中運行支架
90-70系列主機架兼容性
90-70系列主機架不能用于PACSystems RX7i系統。PACSystems RX7i CPU和RX7i以太網模塊不在90-70系列中運行支架
Program blocks Up to 512 program blocks. Maximum size for a block is 128KB.
Memory
(For a detailed listing of memory areas, refer to
the CPU Reference Manual, GFK-2222.)
%I and %Q: 32Kbits for discrete
%AI and %AQ: configurable up to 32Kwords
%W: configurable up to the maximum available user RAM
Managed memory (Symbolic and I/O variables combined):
configurable up to 10 Mbytes
Ethernet Interface Specifications
Web-based data monitoring Up to 16 web server and FTP connections (combined)Important Product Information for this Release
Ethernet Firmware version 6.20 adds support in SNTP for local time zones and daylight savings.
For details, see “New Ethernet Features and Enhancements in Firmware Version 6.20” on page 5. For problems resolved in
this release, see “Ethernet Problems Resolved in Firmware Version 6.20” on page 16.
Hardware version -Jx corrects the hardware ID to enable low battery detection when used with a smart battery.
Important Note: It is recommended that the user change the station manager password to a password other than the default
password. Access to remote station manager will be disabled when the station manager password is set to
the default password.
GE Intelligent Platforms recommends disabling FTP server and/or Web server connections if not used. For
details, see page 19.Updates
The CPE030 and CPE040 can be field upgraded to CPU version 6.75 and Ethernet version 6.20 using the Winloader firmware
upgrade utility and one of the following upgrade kits. Toolkit Release 5.50 or later is required for LREAL data type support.
C Toolkit Release 5.00 Build 16C1 or later is required when the PACSystems CPU
contains firmware Release 5.00 or later.
Notes: C blocks that were built using C Toolkit versions earlier than 5.00 Build 16C1
must be recompiled using a newer toolkit version for use with CPU firmware
release 5.00 or higher.
The Series 90 Toolkit (IC641SWP709/719) is not compatible with PACSystems.Series 90-70 expansion racks are supported by the PACSystems RX7i.
PACSystems RX7i CPUs and the RX7i Ethernet Module do not operate in a Series 90-70
rack.
Series 90-70 Main rack
compatibility
Series 90-70 Main Racks cannot be used in a PACSystems RX7i system.
PACSystems RX7i CPUs and the RX7i Ethernet Module do not operate in a Series 90-70
