PCI and Ethernet
Ethernet is also byte-stream-oriented; the byte having the lowest address
in memory is the first one to be transferred regardless of the endian mode.
Since the Raven maintains address invariance in both little-endian and big-endian mode, no endian issues should arise for Ethernet data.
Big-endian software must still take the byte-swapping effect into account
when accessing the registers of the PCI/Ethernet device, however.
Role of the Universe II ASIC
Because the PCI bus is little-endian while the VMEbus is big-endian, the
Universe PCI/VME bus bridge ASIC performs byte swapping in both
directions (from PCI to VMEbus and from VMEbus to PCI) to maintain
address invariance, regardless of the mode of operation in the processor’s
domain.
VMEbus Domain
The VMEbus is inherently big-endian. All devices connected directly to
the VMEbus must operate in big-endian mode, regardless of the mode of
operation in the processor’s domain.
In big-endian mode, byte-swapping is performed first by the Universe II
ASIC and then by the Raven. The result is transparent to big-endian
software (a desirable effect).
In little-endian mode, however, software must take the byte-swapping
effect of the Universe II ASIC and the address reverse-rearranging effect
of the Raven into account.
For further details on endian considerations, refer to the MVME2600/2700
Series Single Board Computer Programmer’s Reference GuideOverview
This chapter describes the MVME2700 series single board computer on a
block diagram level. Figure 3-1 shows a block diagram of the overall board
architecture. The General Description provides an overview of the
MVME2700, followed by a detailed description of several blocks of
circuitry.
Detailed descriptions of other MVME2700 blocks, including
programmable registers in the ASICs and peripheral chips, can be found in
the MVME2600/2700 Series Single Board Computer Programmer’s
Reference Guide, listed in Appendix D, Related Documentation. Refer to
it for a functional description of the MVME2700 in greater depth.
