Atlas Copco PF3007-C-HW扭矩控制器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
一、產品概述
Atlas Copco PF3007-C-HW 是 PF3000 系列中一款高性能、緊湊型扭矩控制器，主要用于控制 Atlas Copco 的電動擰緊工具（如 Tensor ST、ES、ETX 系列），實現扭矩與角度精確控制。該控制器內置智能擰緊算法，可集成于自動化產線與裝配工位中，適用于對擰緊精度與可追溯性有較高要求的工業應用。
二、技術參數（簡要）
控制方式：扭矩控制、角度控制、時間控制、復合擰緊策略
兼容工具：支持 Tensor ST、ES、ETX 等系列擰緊工具
通信接口：以太網、I/O、RS232、（可選 Profibus/DeviceNet）
數據功能：支持擰緊曲線記錄、追溯碼綁定、錯誤檢測
安裝形式：模塊化設計，適合控制柜或產線工位集成使用
適配軟件：與 ToolsTalk PF 軟件或MES系統集成使用
三、應用領域
1. 汽車制造
動力總成（發動機、變速箱）、底盤系統的關鍵連接螺栓擰緊
儀表臺、車門、座椅等裝配線工位對扭矩一致性要求較高的場合
車體焊裝后的高強度螺絲安裝作業
2. 新能源汽車行業
電池模組安裝、電機驅動系統的高精度擰緊
電控單元、冷卻系統等部件對螺絲角度和扭矩的精細控制
3. 家電與電子產品制造
小家電裝配（如洗衣機、電動工具、電動吸塵器）的批量裝配
消費電子（如電視機、電路模塊）中塑料件或金屬件緊固控制
4. 軌道交通與工程機械
結構連接部位的中高扭矩螺栓擰緊
關鍵安全連接點的質量可追溯裝配過程
5. 工業設備制造
工業機器人、自動化機械、電控柜等結構部件裝配
精密機械組裝，如機床導軌、滑臺、線性傳動系統的精密固定
英文資料：
1、 Product Overview
Atlas Copco PF3007-C-HW is a high-performance, compact torque controller in the PF3000 series, mainly used to control Atlas Copco's electric tightening tools (such as Tensor ST, ES, ETX series), achieving precise control of torque and angle. The controller is equipped with an intelligent tightening algorithm that can be integrated into automated production lines and assembly stations, making it suitable for industrial applications that require high tightening accuracy and traceability.
2、 Technical parameters (brief)
Control methods: torque control, angle control, time control, composite tightening strategy
Compatible tools: Supports tightening tools such as Tensor ST, ES, ETX series, etc
Communication interface: Ethernet I/O、RS232、 (optional Profibus/DeviceNet)
Data function: supports tightening curve recording, traceability code binding, and error detection
Installation form: Modular design, suitable for integrated use in control cabinets or production line workstations
Adaptation software: integrated with ToolsTalk PF software or MES system for use
3、 Application Fields
1. Automobile manufacturing
Tighten the key connecting bolts of the powertrain (engine, gearbox) and chassis system
In situations where assembly line workstations such as instrument panels, car doors, and seats require high torque consistency
Installation of high-strength screws after welding of the vehicle body
2. New energy vehicle industry
High precision tightening of battery module installation and motor drive system
Fine control of screw angle and torque by electronic control unit, cooling system and other components
3. Manufacturing of household appliances and electronic products
Batch assembly of small household appliances (such as washing machines, power tools, and electric vacuum cleaners)
Plastic or metal parts fastening control in consumer electronics (such as televisions, circuit modules)
4. Rail Transit and Engineering Machinery
Tightening of medium to high torque bolts at structural connection points
The quality of key safety connection points can be traced back to the assembly process
5. Industrial equipment manufacturing
Assembly of structural components such as industrial robots, automation machinery, and electrical control cabinets
Precision mechanical assembly, such as precision fixing of machine tool guide rails, slide tables, and linear transmission systems
2.產 品 展 示
