Atlas Copco PF3107-G-HW驅動裝置 PDF資料
1.產 品 資 料 介 紹：
中文資料：
Atlas Copco PF3107-G-HW 驅動裝置
（Power Focus 3100 系列）
產品概述：
PF3107-G-HW 是 Atlas Copco Power Focus 3100 系列中的一款驅動裝置，專為控制單把電動擰緊工具而設計，適用于基本工業裝配環境。該型號具備穩定的擰緊控制功能，并支持?jǐn)?shù)據采集與現場總線通信，滿足中等復雜度生產線的控制需求。
型號說明：
PF3107：Power Focus 3100 型號，適用于單工具控制
G：代表“通用”（General）用途，具備標準控制與通信功能
HW：硬件授權版本（非軟件激活），通過硬件方式啟用功能
核心功能：
控制 Atlas Copco Tensor 系列工具（如 ST、SR）
精確執行扭矩、角度控制和多種擰緊策略
本地?cái)?shù)據采集和追溯功能
工藝參數存儲、錯誤監控和報警功能
可與 PLC 或 MES 系統通訊集成
通信接口與支持協議：
標配有以太網接口
支持 Open Protocol 通信協議
可選適配 DeviceNet、Profibus、Profinet 等（視具體配置）
應用領域：
電子產品與電氣設備裝配
家電制造
汽車零部件小型工位擰緊任務
中小型裝配生產線
需要穩定扭矩控制但對數據處理要求適中的工業應用
產品特點：
結構緊湊，便于集成安裝
穩定可靠，適應多種工業環境
控制精度高，調試簡單
支持常用通訊協議，便于集成到現有產線
可與 Atlas Copco 標準工具快速匹配使用
英文資料：
Atlas Copco PF3107-G-HW Drive Device
(Power Focus 3100 series)
Product Overview:
PF3107-G-HW is a drive device in the Atlas Copco Power Focus 3100 series, designed specifically for controlling single handle electric tightening tools and suitable for basic industrial assembly environments. This model has stable tightening control function and supports data acquisition and fieldbus communication, meeting the control requirements of medium complexity production lines.
Model Description:
PF3107: Power Focus 3100 model, suitable for single tool control
G: Represents' General 'use, with standard control and communication functions
HW: Hardware authorized version (non software activated), enabling functionality through hardware means
Core functions:
Control Atlas Copco Tensor series tools (such as ST, SR)
Accurate execution of torque, angle control, and multiple tightening strategies
Local data collection and traceability function
Process parameter storage, error monitoring, and alarm functions
Can communicate and integrate with PLC or MES systems
Communication interface and supporting protocols:
Equipped with Ethernet interface as standard
Support Open Protocol communication protocol
Optional compatibility with DeviceNet, Profibus, Profinet, etc. (depending on specific configuration)
Application areas:
Assembly of electronic products and electrical equipment
Home appliance manufacturing
Tightening task for small workstations of automotive parts
Small and medium-sized assembly production line
Industrial applications that require stable torque control but moderate data processing requirements
Product features:
Compact structure, easy to integrate and install
Stable and reliable, adaptable to various industrial environments
High control accuracy and simple debugging
Support common communication protocols for easy integration into existing production lines
Can be quickly matched and used with Atlas Copco standard tools
2.產 品 展 示
