Atlas Copco PF4000-C-DN-HW控制器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
Atlas Copco PF4000-C-DN-HW 控制器
產品概述：
PF4000-C-DN-HW 是 Atlas Copco Power Focus 4000 系列中的一款工業級擰緊控制器。該型號專為高精度電動工具提供控制、監測和通信功能，特別適用于對擰緊過程有高可靠性與數據追溯要求的工業裝配環境。
型號說明：
PF4000：Power Focus 4000 系列
C：單通道控制器（支持一把工具）
DN：支持 DeviceNet 通信協議
HW：硬件授權版本（與軟件激活版本區分）
核心功能：
控制和管理 Atlas Copco 電動工具（如 Tensor ST、Tensor S）
支持多種擰緊策略：扭矩控制、角度控制、組合策略等
實時采集并記錄擰緊過程參數
過程錯誤自動報警與停機處理
可與 PLC、MES 系統集成，實現全流程追溯
通信接口與協議：
DeviceNet（工業總線）
USB、本地 I/O
可選 Open Protocol 支持（供 MES 系統調用）
應用領域：
汽車裝配（發動機、底盤、內飾件）
電氣設備和電機總裝
家電制造及模塊化生產
工業自動化控制線體
所有需要扭矩數據追蹤的裝配場景
產品優勢：
工業級可靠性，適用于全天候生產環境
控制精度高，響應速度快
數據記錄全面，支持追溯與質量分析
易于安裝、配置與維護
與 Atlas Copco 工具系統無縫對接
英文資料：
Atlas Copco PF4000-C-DN-HW Controller
Product Overview:
PF4000-C-DN-HW is an industrial grade tightening controller in the Atlas Copco Power Focus 4000 series. This model is designed to provide control, monitoring, and communication functions for high-precision electric tools, especially suitable for industrial assembly environments that require high reliability and data traceability during the tightening process.
Model Description:
PF4000: Power Focus 4000 Series
C: Single channel controller (supports one tool)
DN: Supports DeviceNet communication protocol
HW: Hardware authorization version (distinguished from software activation version)
Core functions:
Control and manage Atlas Copco power tools (such as Tensor ST, Tensor S)
Support multiple tightening strategies: torque control, angle control, combination strategy, etc
Real time collection and recording of tightening process parameters
Automatic alarm and shutdown handling for process errors
Can be integrated with PLC and MES systems to achieve full process traceability
Communication interface and protocol:
DeviceNet (Industrial Bus)
USB、 Local I/O
Optional Open Protocol support (for MES system to call)
Application areas:
Automotive assembly (engine, chassis, interior parts)
Electrical equipment and motor assembly
Home appliance manufacturing and modular production
Industrial automation control line body
All assembly scenarios that require torque data tracking
Product advantages:
Industrial grade reliability, suitable for all-weather production environments
High control accuracy and fast response speed
Comprehensive data recording, supporting traceability and quality analysis
Easy to install, configure, and maintain
Seamless integration with Atlas Copco tool system
2.產 品 展 示
