Atlas Copco PF4000-C-PN-HW驅動器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
Atlas Copco PF4000-C-PN-HW 驅動器
產品概述：
PF4000-C-PN-HW 是 Atlas Copco Power Focus 4000 系列中的一款驅動器型號，用于控制和驅動特定型號的電動擰緊工具。該驅動器集成了扭矩控制、電機管理和通信接口功能，是工業裝配過程中關鍵的控制單元。
命名解析：
PF4000：代表 Power Focus 4000 系列
C：表明是單通道控制單元
PN：支持 PROFINET 通信協議
HW：表示為硬件版本控制器（通常區別于軟件激活版本）
主要功能：
精確控制擰緊扭矩與角度
與 Tensor ST/STB/SRT 系列工具兼容
支持多種擰緊策略（扭矩、角度、時間、組合等）
提供故障檢測與數據記錄功能
可集成進自動化系統，連接 MES 或 PLC
實時過程監控與數據追溯
支持工位互鎖和 I/O 控制
通信接口：
PROFINET（工業以太網）
USB、RS232
可選支持 Open Protocol、以太網/IP、DeviceNet 等（取決于配置）
應用領域：
汽車制造及底盤總成
電子產品裝配
電氣設備生產
高可靠性工業連接場景
需要多工位過程控制與追溯的裝配產線
英文資料：
Atlas Copco PF4000-C-PN-HW Driver
Product Overview:
PF4000-C-PN-HW is a driver model in the Atlas Copco Power Focus 4000 series, used to control and drive specific models of electric tightening tools. This driver integrates torque control, motor management, and communication interface functions, and is a key control unit in industrial assembly processes.
Naming resolution:
PF4000: represents the Power Focus 4000 series
C: Indicating that it is a single channel control unit
PN: Supports PROFINET communication protocol
HW: stands for Hardware Version Controller (usually distinguished from Software Activation Version)
Main functions:
Precise control of tightening torque and angle
Compatible with Tensor ST/STB/SRT series tools
Support multiple tightening strategies (torque, angle, time, combination, etc.)
Provide fault detection and data recording functions
Can be integrated into automation systems and connected to MES or PLC
Real time process monitoring and data tracing
Support workstation interlocking and I/O control
Communication interface:
PROFINET (Industrial Ethernet)
USB、RS232
Optional support for Open Protocol, Ethernet/IP, DeviceNet, etc. (depending on configuration)
Application areas:
Automobile manufacturing and chassis assembly
Electronic product assembly
Electrical equipment production
High reliability industrial connectivity scenarios
Assembly production lines that require multi station process control and traceability
2.產 品 展 示
