Tokyo Electron 2180-021279-11印刷電路板 PDF資料
1.產 品 資 料 介 紹：
中文資料：
Tokyo Electron (TEL) 2180-021279-11 印刷電路板 — 產品應用領域詳解
一、產品功能定位
2180-021279-11 印刷電路板（PCB） 是 Tokyo Electron（TEL）半導體設備內部的重要電子組件，用于承載、連接并驅動各類電子元器件。此 PCB 板在系統中通常負責信號處理、功能邏輯執行或設備控制橋接，是控制系統與執行單元間實現高可靠性、高速數據傳輸?shù)年P(guān)鍵載體。
二、主要應用領域
1. 設備控制子系統中的核心功能板卡
典型功能：
處理數字/模擬信號，完成邏輯控制、放大、濾波、轉換等操作；
擔任控制器模塊的輔助單元或獨立子系統中的主控板；
與溫控、電機驅動、氣體控制、真空系統等功能模塊協作。
應用設備：
CVD、ALD、Etcher 等主機內部；
晶圓搬運與傳輸系統；
晶圓檢測、監控單元；
溫度、氣壓、流量等工藝控制回路。
2. 信號橋接與子系統通信平臺
信號接口類型：
數字 I/O、模擬 I/O、RS-232/422、CAN、以太網或?qū)Ｓ猛ㄐ艆f(xié)議；
可連接控制器模塊、電源板、傳感器、執行器、閥組等；
主要職責：
實現系統內多個模塊的數據通信與協同控制；
對接人機界面（HMI）或主機軟件系統，上傳設備狀態與運行參數。
英文資料：
Tokyo Electron (TEL) 2180-021279-11 Printed Circuit Board - Detailed Explanation of Product Application Fields
1、 Product functional positioning
2180-021279-11 Printed Circuit Board (PCB) is an important electronic component inside Tokyo Electron (TEL) semiconductor equipment, used to carry, connect, and drive various electronic components. This PCB board is usually responsible for signal processing, functional logic execution, or device control bridging in the system, and is a key carrier for achieving high reliability and high-speed data transmission between the control system and the execution unit.
2、 Main application areas
1. Core functional board in the equipment control subsystem
Typical functions:
Process digital/analog signals, complete logic control, amplification, filtering, conversion and other operations;
Serve as the auxiliary unit of the controller module or the main control board in an independent subsystem;
Collaborate with functional modules such as temperature control, motor drive, gas control, vacuum system, etc.
Application devices:
Internal components of CVD, ALD, Etcher and other hosts;
Wafer handling and transportation system;
Wafer inspection and monitoring unit;
Process control circuits for temperature, air pressure, flow rate, etc.
2. Signal bridging and subsystem communication platform
Signal interface type:
Digital I/O, analog I/O, RS-232/422, CAN, Ethernet, or dedicated communication protocols;
Can connect controller modules, power boards, sensors, actuators, valve groups, etc;
Main responsibilities:
Implement data communication and collaborative control among multiple modules within the system;
Docking with human-machine interface (HMI) or host software system, uploading device status and operating parameters.
2.產 品 展 示
