Tokyo Electron CS1B14-000011-12交換器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
Tokyo Electron (TEL) CS1B14-000011-12 交換器 — 產品應用領域詳解
一、產品功能定位
CS1B14-000011-12 交換器是 Tokyo Electron 半導體設備系統中用于數據通信與網絡連接的工業以太網交換機模塊，其主要功能是為設備內部多個子系統之間提供高速、穩定的網絡通信平臺，保障控制信息、工藝數據、監控信號的高效傳輸與同步。
二、主要應用領域
1. 半導體設備內部控制網絡通信核心
設備類型：
光刻設備（Lithography）
CVD/Etch 系統
顯影與清洗系統（Coater/Developer）
自動化搬運平臺（FOUP Loaders、Transfer Modules）
功能作用：
連接主控制器（如 IPC、PLC）與各 I/O 板、傳感器、執行器；
實現分布式控制系統間的數據互通，確保設備運行實時性與同步性。
2. 工藝數據采集與傳輸平臺
應用場景：
將實時工藝數據（溫度、氣壓、電流、位置等）快速傳送至控制主機；
配合人機界面（HMI）、數據庫或 MES 系統，實現數據記錄與分析。
典型接口：
RJ45 千兆/百兆以太網口；
部分版本可能支持光纖 SFP 接口、工業級 PoE 供電。
英文資料：
Tokyo Electron (TEL) CS1B14-00011-12 Converter - Product Application Field Detailed Explanation
1、 Product functional positioning
CS1B14-00011-12 switch is an industrial Ethernet switch module used for data communication and network connection in Tokyo Electron semiconductor equipment systems. Its main function is to provide a high-speed and stable network communication platform for multiple subsystems within the equipment, ensuring efficient transmission and synchronization of control information, process data, and monitoring signals.
2、 Main application areas
1. Communication core of internal control network in semiconductor equipment
Equipment type:
Lithography equipment
CVD/Etch system
Coater/Developer System
Automated Handling Platforms (FOUP Loaders, Transfer Modules)
Function and function:
Connect the main controller (such as IPC, PLC) with various I/O boards, sensors, and actuators;
Realize data interoperability between distributed control systems to ensure real-time and synchronous operation of equipment.
2. Process data collection and transmission platform
Application scenarios:
Quickly transmit real-time process data (temperature, air pressure, current, position, etc.) to the control host;
Collaborate with human-machine interface (HMI), database or MES system to achieve data recording and analysis.
Typical interface:
RJ45 Gigabit/100Mbps Ethernet port;
Some versions may support fiber optic SFP interfaces and industrial grade PoE power supply.
