Tokyo Electron 3M81-024340-14驅動器模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
TEL Tokyo Electron 3M81-024340-14 驅動器模塊
（Driver Module）
產品功能簡介：
3M81-024340-14 驅動器模塊 是 Tokyo Electron（TEL）半導體設備中用于驅動電機、執行器或其他負載的關鍵模塊。它主要承擔電力輸出與控制邏輯執行的雙重作用，在設備自動化系統中屬于動作執行層的核心部件。
主要功能包括：
為步進電機、伺服電機或其他電動執行單元提供驅動電流與控制脈沖
接收來自控制器（如 PLC 或主控板）的信號，執行啟停、轉速、方向控制
實現高精度定位控制，支持加減速曲線與回零邏輯
內置過流、過壓、過溫保護，保障設備穩定運行
與運動控制系統或 I/O 系統協同實現自動化工藝流程
主要應用領域：
1. 晶圓搬運與對位系統
驅動晶圓搬運手臂、升降機構、旋轉臺等關鍵部件
保證晶圓在不同模塊（如 EFEM、Load Port、腔體）之間的準確傳輸和定位
2. 精密運動控制系統
在 TEL Etcher、CVD、PVD 等設備中，驅動氣缸、導軌、電動滑臺實現流程動作
用于載盤機構、裝載機構、門控機構的自動驅動控制
3. 真空與氣體控制設備
控制真空閥門的啟閉動作
驅動壓力調節單元中的微電機或線性執行器
英文資料：
TEL Tokyo Electron 3M81-024340-14 Driver Module
（Driver Module）
Product Function Introduction:
The 3M81-024340-14 driver module is a critical module used in Tokyo Electron (TEL) semiconductor equipment to drive motors, actuators, or other loads. It mainly plays a dual role in power output and control logic execution, and is a core component of the action execution layer in equipment automation systems.
The main functions include:
Provide driving current and control pulses for stepper motors, servo motors, or other electric execution units
Receive signals from controllers (such as PLCs or main control boards) to perform start stop, speed, and direction control
Realize high-precision positioning control, support acceleration and deceleration curves and zero return logic
Built in overcurrent, overvoltage, and overtemperature protection to ensure stable operation of the equipment
Collaborate with motion control systems or I/O systems to achieve automated process flow
Main application areas:
1. Wafer handling and alignment system
Drive key components such as wafer handling arms, lifting mechanisms, and rotating tables
Ensure accurate transfer and positioning of wafers between different modules (such as EFEM, load ports, chambers)
2. Precision motion control system
In TEL Etcher, CVD, PVD and other equipment, the driving cylinder, guide rail, and electric slide table are used to achieve process actions
Automatic drive control for loading mechanisms, loading mechanisms, and door control mechanisms
3. Vacuum and gas control equipment
Control the opening and closing action of the vacuum valve
Micro motors or linear actuators in the driving pressure regulating unit
