Tokyo Electron 381-600290-7控制主板卡件 PDF資料
1.產 品 資 料 介 紹：
中文資料：
TEL Tokyo Electron 381-600290-7 控制主板卡件簡介
一、基本信息
產品型號：381-600290-7
產品名稱：控制主板卡件（AD Mother Board）
制造商：Tokyo Electron Ltd.（TEL）
卡件類型：主控系統模塊之一，常用于信號處理與設備管理控制架構中
二、功能描述
信號處理核心
用于接收、轉換并調度來自各個子系統的模擬或數字信號，是設備數據傳輸?shù)闹袠小?/p>主控通信橋接
與主CPU板、I/O模塊、傳感器板等進行聯動，構成設備核心控制網絡。設備邏輯控制平臺
通過軟件定義的邏輯控制機制協調設備執行動作，如氣閥切換、溫控反饋、流量調節等。
三、應用領域
廣泛應用于 TEL 的半導體工藝設備中，特別是蝕刻機、CVD、涂膠顯影設備等。
常用于控制系統的主干線路中，是信號分發和系統運行邏輯的關鍵模塊。
適合設備的定期維護、故障更換或系統升級所使用的替代卡件。
四、使用建議
檢查硬件兼容性：與目標設備的控制架構、背板信號標準及電壓規格保持一致。
遵循安裝流程：確保在斷電情況下進行更換，插接過程中避免彎折或接觸不良。
運行前測試：更換或維修完成后應進行通電功能測試，確認控制邏輯正常。
定期維護檢查：重點檢查接插件、電容、電阻元件和PCB焊點的可靠性，防止老化失效。
英文資料：
Introduction to TEL Tokyo Electron 381-600290-7 Control Motherboard Card
1、 Basic Information
Product model: 381-600290-7
Product Name: Control Motherboard Card (AD Mother Board)
Manufacturer: Tokyo Electron Ltd. (TEL)
Card type: One of the main control system modules, commonly used in signal processing and equipment management control architecture
2、 Function Description
Signal processing core
Used to receive, convert, and schedule analog or digital signals from various subsystems, it is the hub of device data transmission.
Main control communication bridge
Integrate with the main CPU board, I/O modules, sensor board, etc. to form the core control network of the device.
Equipment Logic Control Platform
Coordinate device execution actions through software defined logic control mechanisms, such as valve switching, temperature control feedback, flow regulation, etc.
3、 Application Fields
Widely used in TEL's semiconductor process equipment, especially etching machines CVD、 Glue coating and developing equipment, etc.
Commonly used in the backbone circuit of control systems, it is a key module for signal distribution and system operation logic.
Alternative cards suitable for regular maintenance, fault replacement, or system upgrades of equipment.
4、 Usage suggestions
Check hardware compatibility: Maintain consistency with the control architecture, backplane signal standards, and voltage specifications of the target device.
Follow the installation process: Ensure replacement is carried out in the event of power failure, and avoid bending or poor contact during the insertion process.
Pre operation testing: After replacement or repair, a power on function test should be conducted to confirm that the control logic is normal.
Regular maintenance inspection: Focus on checking the reliability of connectors, capacitors, resistor components, and PCB solder joints to prevent aging and failure.
