Tokyo Electron 3M87-024252-23控制器模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
TEL Tokyo Electron 3M87-024252-23 控制器模塊 是一款應用于半導體制造設備中的控制核心單元模塊，主要用于對設備各個功能模塊（如氣體系統、溫控系統、運動機構等）進行統一管理、邏輯運算和控制指令下發，是實現自動化精密工藝控制的關鍵組成部分。
一、基本信息
產品型號： 3M87-024252-23
產品名稱： 控制器模塊（Controller Module）
制造商： Tokyo Electron Ltd.（TEL）
模塊類型： 嵌入式控制系統組件 / 工藝控制卡件
適用平臺： 可能用于 TEL 的涂膠顯影（Coater/Developer）、CVD、Etcher 或 ALD 系統等。
二、核心功能
工藝流程控制
運行 TEL 設備控制邏輯，用于管理各工藝步驟的啟停、切換、計時、同步等。
外圍模塊協調
與 I/O 板、氣閥控制板、驅動模塊、溫控板等協同工作，執行邏輯動作控制。
設備狀態監控與反饋
實時采集各子系統的運行狀態，并根據設定條件作出判斷、反饋或報警。
與主系統通信
通過系統總線（如 TEL 專用總線、Ethernet、CAN 等）與主機或上位系統交互數據。
嵌入式程序運行
內部可能搭載嵌入式處理器與固化軟件，用于執行特定工藝控制程序。
三、典型應用領域
涂膠顯影系統（Coater/Developer）
控制晶圓傳輸、旋轉、涂膠、顯影步驟的節拍與條件判斷。
CVD / ALD 設備
管理反應氣體的切換、溫度設定、沉積過程的節拍邏輯。
等離子蝕刻系統
控制等離子源開啟/關閉、RF電源狀態、腔體氣壓與氣流調節等關鍵參數。
后段封裝/清洗模塊
實現流體/溶液控制、泵閥切換、循環時間控制、廢液排放等操作管理。
英文資料：
The TEL Tokyo Electron 3M87-024252-23 controller module is a control core unit module used in semiconductor manufacturing equipment. It is mainly used for unified management, logical operation, and control instruction issuance of various functional modules of the equipment (such as gas system, temperature control system, motion mechanism, etc.), and is a key component for achieving automated precision process control.
1、 Basic Information
Product model: 3M87-024252-23
Product Name: Controller Module
Manufacturer: Tokyo Electron Ltd. (TEL)
Module Type: Embedded Control System Components/Process Control Cards
Applicable platforms: May be used for TEL coating/developer, CVD, Etcher, or ALD systems, etc.
2、 Core functions
Process control
Run TEL device control logic to manage the start stop, switching, timing, synchronization, etc. of each process step.
Peripheral module coordination
Collaborate with I/O board, air valve control board, driver module, temperature control board, etc. to execute logical action control.
Equipment status monitoring and feedback
Real time collection of the operating status of each subsystem, and making judgments, feedback, or alarms based on set conditions.
Communicate with the main system
Interact data with the host or upper system through system buses such as TEL dedicated buses, Ethernet, CAN, etc.
Embedded program running
Internally, it may be equipped with embedded processors and fixed software for executing specific process control programs.
3、 Typical application areas
Coater/Developer system
Control the rhythm and condition judgment of wafer transfer, rotation, coating, and development steps.
CVD/ALD equipment
Manage the switching of reaction gases, temperature settings, and the rhythm logic of the deposition process.
Plasma etching system
Control key parameters such as plasma source on/off, RF power status, chamber pressure and airflow regulation.
Rear packaging/cleaning module
Implement fluid/solution control, pump valve switching, circulation time control, waste liquid discharge and other operational management.
