地址以十六進制數字輸入，例如20000對應地址：00020000美元。地址或起始地址范圍的，可以由形式為^S、^S、^U或^U的后綴限定其中，S或S定義監控器地址空間，U或U定義
用戶地址空間。默認情況下，當未指定限定符時，是主管。
一旦輸入了限定符，它對所有地址都有效輸入該命令序列，直到187Bug重新輸入或者提供了另一個限定符。地址的另一種形式是Rnn，它告訴bug使用包含在CPU寄存器Rnn中的地址，其中nn=00到31（即。，00, 01,..., 或31）。
HVC-02B高壓控制板在范圍指定為addr del addr的命令中，以及選擇大小選項H或W時，第二（結束）僅當?shù)诙€(gè)地址是半個單詞或單詞的適當邊界，分別地否則，范圍將被截?cái)?，以便作用的最后一個字節位于正確的邊界稱為偏移寄存器的八個偽寄存器（Z0到Z7）是用于簡化可重定位和位置獨立模塊的調試。這些類型程序中的列表文件通常從地址（通常為0）開始，該地址不是它們已加載，因此很難關聯列表中的地址加載的程序中包含地址。偏移寄存器求解通過考慮這種差異并強制以相對地址+偏移量格式顯示地址。抵消寄存器的范圍可調，甚至可能重疊范圍。每個偏移寄存器的范圍由兩個地址設置：底部和頂部。指定偏移量的基地址和頂?shù)刂芳拇嫫髟O(shè)置其范圍。如果一個地址分為兩個或多個偏移寄存器的范圍越多，產生最小偏移的范圍是被選中的。注：相對地址限制為1MB（5位），無論最近偏移寄存器的范圍如何。端口號一些187Bug命令允許用戶選擇端口用于輸入或輸出。有效的端口號可能是用于這些命令的有：1.MVME187 EIA-232-D調試（終端端口0或00）（端口1）在MVME187 P2連接器上）。有時被稱為“控制臺端口”，用于交互用戶輸入/輸出
2.MVME187 EIA-232-D（終端端口1或01）（上的端口2）MVME187 P2連接器）。有時被稱為“主持人”端口”，這是下載、上載、，并發模式和透明模式。
Addresses are entered as a hexadecimal number, e.g., 20000 would
correspond to address $00020000. The address, or starting address
of a range, can be qualified by a suffix of the form ^S, ^s, ^U, or ^u
where S or s defines Supervisor address space, and U or u defines
user address space. The default, when the qualifier is not specified,
is Supervisor.
Once a qualifier has been entered, it remains valid for all addresses
entered for that command sequence, until the 187Bug is reentered
or another qualifier is provided.
An alternate form of Address is Rnn, which tells the bug to use the
address contained in CPU Register Rnn, where nn=00 thru 31 (i.e.,
00, 01,..., or 31). In commands with range specified as addr del addr, and
with size option H or W chosen, data at the second
(ending) address is acted on only if the second address
is a proper boundary for a half-word or word,
respectively. Otherwise, the range is truncated so that
the last byte acted upon is at an address that is a proper
boundaryEight pseudo-registers (Z0 through Z7) called offset registers are
used to simplify the debugging of relocatable and positionindependent modules. The listing files in these types of programs
usually start at an address (normally 0) that is not the one at which
they are loaded, so it is harder to correlate addresses in the listing
with addresses in the loaded program. The offset registers solve
this problem by taking into account this difference and forcing the
display of addresses in a relative address+offset format. Offset
registers have adjustable ranges and may even have overlapping
ranges. The range for each offset register is set by two addresses:
base and top. Specifying the base and top addresses for an offset
register sets its range. In the event that an address falls in two or
more offset registers' ranges, the one that yields the least offset is
chosen.
Note Relative addresses are limited to 1MB (5 digits),
regardless of the range of the closest offset register.
Port Numbers
Some 187Bug commands give the user the option to choose the port
to be used to input or output. Valid port numbers which may be
used for these commands are:
1. MVME187 EIA-232-D Debug (Terminal Port 0 or 00) (PORT 1
on the MVME187 P2 connector). Sometimes known as the
“console port”, it is used for interactive user input/output by
default.
2. MVME187 EIA-232-D (Terminal Port 1 or 01) (PORT 2 on the
MVME187 P2 connector). Sometimes known as the “host
port”, this is the default for downloading, uploading,
concurrent mode, and transparent modes
