Tokyo Electron 3281-000034-15 半導體模塊 PDF資料
1.產 品 資 料 介 紹:
中文資料:
TEL Tokyo Electron 3281-000034-15 半導體模塊 是一款用于半導體制造設備中的專用功能模塊,屬于 TEL Tokyo Electron 的定制硬件,廣泛部署于其刻蝕、CVD、清洗和輸送等工藝設備中。該模塊按 TEL 命名規則,歸類于 3281 系列,通常表示電氣控制、信號處理或通信接口類的功能模塊。
以下是該模塊的詳細功能與應用領域分析(無圖案):
一、基本信息
產品型號: 3281-000034-15
產品名稱: 半導體設備專用模塊
制造商: Tokyo Electron Ltd.(TEL)
模塊類型: 控制/通信/邏輯處理單元(依據TEL設備模塊體系)
二、核心功能(依據編號結構與TEL模塊特性推測)
信號中繼與接口管理
實現設備內部多個子系統之間的電信號橋接;
提供信號緩沖、轉換、電平適配等功能,確保系統通信可靠穩定。
通信與總線接口處理
支持 TEL 內部控制總線、I/O 接口總線或外部通信協議(如 RS-232、TTL、CAN等);
用于主控板(如 E244 系列)與從屬設備之間的命令和狀態傳輸。
狀態監控與邏輯執行
集成控制邏輯器件(如 FPGA、邏輯門陣列),用于處理輸入信號并驅動控制邏輯;
可能帶有狀態燈、錯誤檢測、設備聯鎖等功能。
模塊化連接
可插入 TEL 系統控制機架或背板;
與 E249、BX81、1B80 等系列模塊配套,組成完整工藝控制鏈路。
英文資料:
TEL Tokyo Electron 3281-000034-15 semiconductor module is a specialized functional module used in semiconductor manufacturing equipment, belonging to TEL Tokyo Electron's customized hardware, widely deployed in its etching CVD、 In process equipment such as cleaning and conveying. This module is classified under the 3281 series according to the TEL naming convention, typically representing functional modules in the fields of electrical control, signal processing, or communication interfaces.
The following is a detailed analysis of the module's functions and application areas (without patterns):
1、 Basic Information
Product model: 3281-000034-15
Product Name: Semiconductor Equipment Dedicated Module
Manufacturer: Tokyo Electron Ltd. (TEL)
Module type: Control/Communication/Logic Processing Unit (based on TEL device module system)
2、 Core functions (inferred based on numbering structure and TEL module characteristics)
Signal Relay and Interface Management
Realize electrical signal bridging between multiple subsystems within the device;
Provide functions such as signal buffering, conversion, and level adaptation to ensure reliable and stable system communication.
Communication and bus interface processing
Support TEL internal control bus, I/O interface bus, or external communication protocols (such as RS-232, TTL, CAN, etc.);
Used for command and status transmission between the main control board (such as E244 series) and slave devices.
Status monitoring and logic execution
Integrated control logic devices (such as FPGA, logic gate array) are used to process input signals and drive control logic;
It may have functions such as status lights, error detection, and equipment interlocking.
Modular connection
Can be inserted into TEL system control rack or backplane;
Paired with E249, BX81, 1B80 and other series modules, it forms a complete process control chain.
