Tokyo Electron 408-500111-3自動裝載機板 PDF資料
1.產 品 資 料 介 紹：
中文資料：
TEL Tokyo Electron 408-500111-3 自動裝載機板 是東京電子（TEL）半導體制造設備中用于控制晶圓自動裝載/卸載裝置的專用控制電路板。該板卡通常安裝于前端裝載系統（Front-End Module, FEM）或自動化搬運系統中，實現晶圓盒（FOUP/SMIF）與工藝艙室之間的高精度傳送。
一、產品概述
| 項目 | 內容 |
|---|---|
| 產品名稱 | 自動裝載機板（Auto Loader Board） |
| 產品型號 | 408-500111-3 |
| 制造廠商 | Tokyo Electron Ltd.（東京電子） |
| 安裝位置 | 晶圓自動搬運系統/前端模塊控制單元內部 |
| 功能定位 | 晶圓裝載與卸載機構的控制與狀態管理 |
二、核心功能
自動裝載控制
控制機械臂、升降平臺、真空吸附系統等完成晶圓自動裝載動作；
管理晶圓盒對接、艙門開啟/關閉、Wafer對準等精細動作。
動作信號輸出與反饋采集
輸出多路驅動信號，驅動步進電機或伺服系統執行搬運動作；
采集傳感器反饋，如位置傳感器、對位傳感器、門禁狀態等。
狀態監測與異常處理
實時監控自動裝載系統工作狀態，支持中斷、報警與自診斷功能；
保障晶圓搬運過程的可靠性與安全性。
三、典型應用領域
TEL 涂膠顯影機（Coater/Developer）：自動裝載晶圓至旋涂/顯影腔體；
蝕刻設備（Etcher）、清洗設備（Cleaner）：控制晶圓從前端到腔體的精密轉移；
前端模塊（FEM） 與 中控系統 的連接橋梁。
英文資料：
The TEL Tokyo Electron 408-500111-3 automatic loader board is a dedicated control circuit board used in the semiconductor manufacturing equipment of Tokyo Electronics (TEL) to control the automatic wafer loading/unloading device. This board is usually installed in the Front End Module (FEM) or automated handling system to achieve high-precision transfer between the wafer box (FOUP/SMIF) and the process compartment.
1、 Product Overview
Project Content
Product Name: Auto Loader Board
Product model 408-500111-3
Manufacturer Tokyo Electron Ltd
Installation location: Inside the wafer automatic handling system/front-end module control unit
Control and status management of functional positioning wafer loading and unloading mechanism
2、 Core functions
Automatic loading control
Control the robotic arm, lifting platform, vacuum adsorption system, etc. to complete the automatic wafer loading action;
Manage precise actions such as docking of crystal round boxes, opening/closing of cabin doors, and alignment of wafers.
Action signal output and feedback acquisition
Output multiple drive signals to drive stepper motors or servo systems to perform handling actions;
Collect sensor feedback, such as position sensors, alignment sensors, access control status, etc.
Status monitoring and exception handling
Real time monitoring of the working status of the automatic loading system, supporting interrupt, alarm, and self diagnostic functions;
Ensure the reliability and safety of the wafer handling process.
3、 Typical application areas
TEL Coater/Developer: Automatically loads wafers into spin coating/development chambers;
Etcher and Cleaner: Control the precise transfer of wafers from the front end to the cavity;
The connection bridge between the front-end module (FEM) and the central control system.
2.產 品 展 示
