Tokyo Electron 2184-020028-12模擬輸入電子模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
TEL Tokyo Electron 2184-020028-12 模擬輸入電子模塊 是東京電子公司用于半導體制造設備中的一種功能性電子模塊，專門用于采集來自設備內部傳感器或工藝控制系統的模擬信號（Analog Input），并將其轉換為可供主控系統處理的標準信號格式，是晶圓制造設備控制鏈中的關鍵一環。
一、產品基本信息
| 項目 | 內容 |
|---|---|
| 產品名稱 | 模擬輸入電子模塊 |
| 型號 | 2184-020028-12 |
| 所屬系統 | Tokyo Electron 半導體設備 |
| 功能類型 | 模擬信號采集與輸入接口 |
二、主要功能
模擬信號采集
接收來自溫度傳感器、壓力傳感器、氣體流量計、位置反饋器等設備的連續模擬電信號（如0–5V、0–10V、4–20mA等）；
模塊內部具備A/D轉換功能，將模擬信號數字化，以供控制系統進一步處理。
信號隔離與穩定輸入
具備電氣隔離能力，有效避免外部信號干擾影響主控系統；
提高系統整體抗噪能力和運行穩定性。
數據上傳與工藝控制支持
將采集到的參數實時上傳至主控制單元，用于閉環控制邏輯；
可用于聯動執行機構實現動態工藝調整，如溫控反饋、流量調節等。
三、應用領域
半導體前道工藝設備
應用于TEL晶圓制造設備如涂膠顯影設備（Clean Track）、蝕刻機（Etcher）、清洗設備等；
采集工藝關鍵變量用于實時監測與控制。
環境參數采集系統
安裝于真空腔體、加熱平臺、氣體供應單元等設備部位；
實時采集溫度、壓力、氣體流量等模擬量信息。
設備維護與診斷
工程師可通過該模塊獲取詳細工藝參數，進行設備診斷與調試；
模塊損壞或老化時，可更換以恢復信號鏈路功能。
英文資料：
TEL Tokyo Electron 2184-020228-12 Analog Input Electronic Module is a functional electronic module used by Tokyo Electronics Corporation in semiconductor manufacturing equipment. It is specifically designed to collect analog signals (Analog Input) from internal sensors or process control systems of the equipment, and convert them into a standard signal format that can be processed by the main control system. It is a key link in the control chain of wafer manufacturing equipment.
1、 Basic Product Information
Project Content
Product Name Analog Input Electronic Module
Model 2184-020228-12
Tokyo Electron Semiconductor Equipment System
Function type: Analog signal acquisition and input interface
2、 Main functions
Analog signal acquisition
Receive continuous analog electrical signals (such as 0-5V, 0-10V, 4-20mA, etc.) from temperature sensors, pressure sensors, gas flow meters, position feedback devices, and other equipment;
The module has an A/D conversion function inside, which digitizes analog signals for further processing by the control system.
Signal isolation and stable input
Capable of electrical isolation, effectively avoiding external signal interference affecting the main control system;
Improve the overall noise resistance and operational stability of the system.
Data upload and process control support
Upload the collected parameters in real-time to the main control unit for closed-loop control logic;
It can be used for dynamic process adjustment of linked actuators, such as temperature control feedback, flow regulation, etc.
3、 Application Fields
Semiconductor front-end process equipment
Applied to TEL wafer manufacturing equipment such as coating and developing equipment (Clean Track), etching machines (Etcher), cleaning equipment, etc;
Collect key process variables for real-time monitoring and control.
Environmental parameter collection system
Installed in equipment parts such as vacuum chambers, heating platforms, gas supply units, etc;
Real time collection of analog information such as temperature, pressure, and gas flow rate.
Equipment maintenance and diagnosis
Engineers can obtain detailed process parameters through this module for equipment diagnosis and debugging;
When the module is damaged or aged, it can be replaced to restore the signal link function.
