ABB 3BHE014377R0001 PVD164激勵板 PDF資料
1.產 品 資 料 介 紹：
中文資料：
3BHE014377R0001 PVD164 激勵板 是 ABB 公司的 PVD 系列伺服驅動系統中的一個關鍵部件，主要用于驅動和控制精密伺服電機。它通過處理控制信號并將其轉換為伺服電機所需的電流、頻率和電壓信號來執行電機的運動控制任務。
主要特點與功能：
信號轉換和放大：
- 激勵板的主要作用是將控制系統提供的低電平信號轉換為驅動電機所需的高電流輸出信號，確保伺服電機能夠精確地執行運動指令。
高效的反饋控制：
- 激勵板會接收并處理來自伺服電機的反饋信號，如位置、速度和電流，確保電機運動的穩定性與準確性，并實時調整驅動信號以優化電機性能。
精確的速度與位置控制：
- 在精密控制要求高的應用中，PVD164 激勵板能夠保證電機在各類復雜工況下的精確定位和運動，適應快速響應的控制需求。
過載保護與故障診斷：
- 激勵板內置多種保護機制，包括過載保護、過壓保護和過熱保護，確保系統在極端工況下也能安全運行。同時，它還能通過內置診斷功能實時監控驅動系統的狀態。
高集成度：
- 該激勵板具有高集成度，減少了系統中多個部件的復雜性，簡化了安裝和維護，同時提高了系統的可靠性和運行效率。
英文資料：
3BHE014377R0001 PVD164 excitation board is a key component in ABB's PVD series servo drive system, mainly used to drive and control precision servo motors. It performs motor motion control tasks by processing control signals and converting them into the current, frequency, and voltage signals required by servo motors.
Main features and functions:
Signal conversion and amplification:
The main function of the excitation board is to convert the low-level signal provided by the control system into the high current output signal required to drive the motor, ensuring that the servo motor can accurately execute motion commands.
Efficient feedback control:
The excitation board will receive and process feedback signals from the servo motor, such as position, speed, and current, to ensure the stability and accuracy of the motor movement, and adjust the drive signal in real time to optimize motor performance.
Accurate speed and position control:
In applications that require high precision control, the PVD164 excitation board can ensure precise positioning and motion of the motor under various complex working conditions, adapting to fast response control requirements.
Overload protection and fault diagnosis:
The incentive board is equipped with multiple protection mechanisms, including overload protection, overvoltage protection, and overheating protection, to ensure the safe operation of the system even under extreme working conditions. At the same time, it can also monitor the status of the drive system in real time through its built-in diagnostic function.
High integration:
This incentive board has high integration, reducing the complexity of multiple components in the system, simplifying installation and maintenance, while improving the reliability and operational efficiency of the system.
2.產 品 展 示
