Honeywell 51405098-100接口模塊 PDF資料
1.產 品 資 料 介 紹：
中文資料：
Honeywell 51405098-100 接口模塊 是一款專為工業自動化和控制系統設計的模塊化組件，用于支持各種工業協議和設備的通信接口。它廣泛應用于 Honeywell 的分布式控制系統 (DCS) 和其他自動化系統中，為控制器與現場設備之間提供可靠、高效的數據傳輸橋梁。
產品概述
品牌：
- Honeywell (霍尼韋爾)
型號：
- 51405098-100
類型：
- 接口模塊 (Interface Module)
功能：
- 提供多種通信接口，適配不同工業現場設備
- 支持?jǐn)?shù)據傳輸、協議轉換及信號管理
主要特點
多協議支持：
- 支持 Honeywell 專有協議、Modbus、Ethernet、TCP/IP 等多種通信協議。
高兼容性：
- 可與不同型號的 DCS、PLC、傳感器和執行器連接，兼容性強。
模塊化設計：
- 易于集成和擴展，支持系統靈活配置。
實時通信能力：
- 低延遲、高帶寬的數據傳輸，滿足實時控制需求。
內置診斷功能：
- 提供運行狀態監控和故障檢測，提升維護效率。
工業級設計：
- 具備高抗干擾性和高可靠性，適用于嚴苛環境。
技術規格
| 參數 | 詳細信息 |
|---|---|
| 支持協議 | Modbus, Ethernet, TCP/IP, Honeywell 專有協議 |
| 電源要求 | 24V DC 或由系統供電 |
| 功耗 | ≤5W |
| 接口類型 | 標準工業通信接口（如 RS485、以太網等） |
| 數據速率 | 支持高達 1 Gbps 的數據傳輸速率 |
| 工作溫度范圍 | -20°C 至 +60°C |
| 存儲溫度范圍 | -40°C 至 +85°C |
| 濕度范圍 | 5% 至 95%（無冷凝） |
| 安裝方式 | DIN 導軌或機柜安裝 |
| 診斷功能 | 支持實時錯誤日志記錄與警報功能 |
| 尺寸 | 緊湊型模塊，節省空間設計 |
英文資料：
The Honeywell 51405098-100 interface module is a modular component designed specifically for industrial automation and control systems, used to support communication interfaces for various industrial protocols and devices. It is widely used in Honeywell's distributed control systems (DCS) and other automation systems, providing a reliable and efficient data transmission bridge between controllers and field devices.
Product Overview
Brand:
Honeywell
model:
51405098-100
Type:
Interface Module
Function:
Provide multiple communication interfaces to adapt to different industrial field devices
Support data transmission, protocol conversion, and signal management
main features
Multi protocol support:
Supports various communication protocols such as Honeywell proprietary protocols, Modbus, Ethernet, TCP/IP, etc.
High compatibility:
Can be connected to different models of DCS, PLC, sensors, and actuators, with strong compatibility.
Modular design:
Easy to integrate and expand, supporting flexible system configuration.
Real time communication capability:
Low latency and high bandwidth data transmission to meet real-time control requirements.
Built in diagnostic function:
Provide operational status monitoring and fault detection to improve maintenance efficiency.
Industrial grade design:
Featuring high anti-interference and reliability, suitable for harsh environments.
technical specifications
Detailed parameter information
Supports protocols Modbus, Ethernet, TCP/IP, and Honeywell proprietary protocols
Power requirement: 24V DC or powered by the system
Power consumption ≤ 5W
Interface type standard industrial communication interface (such as RS485, Ethernet, etc.)
Data rate support up to 1 Gbps data transmission rate
Working temperature range -20 ° C to+60 ° C
Storage temperature range -40 ° C to+85 ° C
Humidity range 5% to 95% (non condensing)
Installation method: DIN rail or cabinet installation
Diagnostic function supports real-time error logging and alarm function
Compact size module, space saving design
2.產 品 展 示
