Brooks 002-7090-11 晶圓傳輸機器人 PDF資料
1.產 品 資 料 介 紹：
中文資料：
Brooks 002-7090-11 晶圓傳輸機器人 是Brooks Automation公司專為半導體和電子制造業設計的一款高性能晶圓搬運機器人。該機器人用于在不同工藝設備之間搬運晶圓，幫助實現生產流程的自動化、精準化和高效化。它廣泛應用于半導體制造中的多個環節，如晶圓清洗、蝕刻、涂層、曝光和檢測等工藝步驟。
主要特點：
高精度定位與搬運：
- Brooks 002-7090-11 機器人采用先進的定位技術，能夠?qū)崿F(xiàn)亞微米級的定位精度，確保晶圓在傳輸過程中的位置準確無誤。
- 其搬運系統經過優化，可以在高速度下維持穩定性，降低晶圓傳輸過程中的振動，減少對晶圓表面的潛在損傷。
多自由度運動控制：
- 配備多軸、多自由度控制系統，能夠在不同的平面上移動和旋轉晶圓，滿足復雜工藝對位置和角度的精確要求。這一功能尤其適合需要調整晶圓朝向或高度的工藝步驟。
潔凈室兼容性：
- 設計符合半導體行業的潔凈室標準，具有低顆粒排放特性，能夠在超凈環境中長期穩定運行，避免對晶圓表面造成污染。
- 材質和設計都經過優化，可在潔凈室的高要求環境下運行，同時降低維護需求。
高速傳輸能力：
- Brooks 002-7090-11 機器人在保持精度的同時具有快速搬運能力，有助于縮短工藝設備之間的傳輸時間，從而提高生產效率。
- 支持連續搬運多個晶圓，適合高產量的生產線，優化了制造流程的整體速度。
模塊化設計與靈活性：
- 采用模塊化設計，能夠輕松集成到不同的自動化設備或生產線中，適應性強。用戶可以根據生產需求靈活配置，便于擴展和升級。
- 支持與其他Brooks設備以及第三方控制系統的集成，確保整個自動化系統的兼容性和一致性。
智能化控制與反饋系統：
- 配備智能控制系統，支持實時監控和位置調整，能夠根據晶圓位置自動校正，確保搬運過程的穩定和準確。
- 具備自診斷功能，能夠檢測并反饋自身運行狀態，降低停機時間，便于運維人員及時響應。
英文資料：
The Brooks 002-7090-11 wafer transfer robot is a high-performance wafer handling robot designed by Brooks Automation specifically for the semiconductor and electronic manufacturing industries. This robot is used to transport wafers between different process equipment, helping to achieve automation, precision, and efficiency in the production process. It is widely used in multiple stages of semiconductor manufacturing, such as wafer cleaning, etching, coating, exposure, and inspection processes.
Main features:
High precision positioning and handling:
The Brooks 002-7090-11 robot adopts advanced positioning technology, which can achieve sub micron level positioning accuracy and ensure accurate positioning of wafers during transportation.
The handling system has been optimized to maintain stability at high speeds, reduce vibration during wafer transport, and minimize potential damage to the wafer surface.
Multi degree of freedom motion control:
Equipped with a multi axis and multi degree of freedom control system, the wafer can be moved and rotated on different planes to meet the precise requirements of complex processes for position and angle. This feature is particularly suitable for process steps that require adjusting wafer orientation or height.
Cleanroom compatibility:
Designed to meet the cleanroom standards of the semiconductor industry, with low particle emission characteristics, capable of long-term stable operation in ultra clean environments, and avoiding contamination of wafer surfaces.
The material and design have been optimized to operate in high demand environments in clean rooms while reducing maintenance requirements.
High speed transmission capability:
The Brooks 002-7090-11 robot has fast handling capabilities while maintaining accuracy, which helps shorten the transfer time between process equipment and improve production efficiency.
Supports continuous handling of multiple wafers, suitable for high-yield production lines, optimizing the overall speed of the manufacturing process.
Modular design and flexibility:
Adopting modular design, it can be easily integrated into different automation equipment or production lines, with strong adaptability. Users can flexibly configure according to production needs, making it easy to expand and upgrade.
Support integration with other Brooks devices and third-party control systems to ensure compatibility and consistency of the entire automation system.
Intelligent control and feedback system:
Equipped with an intelligent control system that supports real-time monitoring and position adjustment, it can automatically correct the wafer position to ensure stability and accuracy during the handling process.
Equipped with self diagnostic function, it can detect and provide feedback on its own operating status, reduce downtime, and facilitate timely response by operation and maintenance personnel.
2.產 品 展 示
