Genius總線控制器文檔
Global Data is data that is automatically and repeatedly broadcast by a GBC. The Series 90-30
GBC can send up to 128 bytes of Global Data each bus scan. It can receive up to 128 bytes of
Global Data each bus scan from each GBC on its bus.
Sending Global Data
Once set up by configuration, Global Data is broadcast automatically. Other devices that receive
the Global Data sent by a Series 90-30 PLC place it in these memory locations:
Series 90-30 PLC Sends
Global Data To: Other CPU Places Global Data in these Memory Location:
Series 90-30 PLC %I, %Q, %G, %R, %AI, %AQ. Memory type and beginning
address are chosen during configuration of the receiving GBC.
Series 90-30 GCM+ %I, %Q, %G, %R, %AI, %AQ
Series 90-30 PLC/GCM %G memory location corresponding to Device Number (16-23)
of the Series 90-30 GBC that sent the data.
Series Six PLC Register memory. Beginning Series Six address selected during
configuration of the Series 90-30 GBC that sent the data.
Series Five PLC Register memory. Beginning Series Five address selected during
configuration of the Series 90-30 GBC that sent the data.
Computer PCIM or QBIM Input Table Segment corresponding to Device
Number of the Series 90-30 GBC that sent the data.
Receiving Global Data
The GBC can be configured to receive or ignore Global Data from any other GBC. The memory
type and length for incoming Global Data are also selected during configuration. The Series 90-30
CPU can place incoming Global Data in %I, %Q, %G, %R, %AI, or %AQ memory.
