TRICONEX A03481S2三重冗余處理器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
TRICONEX A03481S2 是一種三重冗余處理器模塊，屬于 Triconex 系列安全系統的重要組成部分。該模塊專為關鍵任務和高安全性要求的工業環境設計，利用三重模塊冗余 (TMR) 架構提供高度可靠的控制和保護功能。
主要特點和功能
三重模塊冗余 (TMR) 架構：
- A03481S2 模塊采用 TMR 架構，包含三個獨立的、并行運行的處理單元。每個處理單元同時處理相同的任務，結果通過投票機制決定最終輸出，確保系統即使在一個處理單元發生故障時仍能正常運行。這種設計大大提高了系統的可靠性和安全性。
高安全性：
- 模塊符合 SIL 3 安全等級，是高安全性應用場合的理想選擇。它在工業自動化和安全保護系統中提供卓越的故障檢測和容錯能力，確保系統在關鍵任務中的可靠運行。
實時處理與控制：
- A03481S2 具備強大的實時處理能力，能夠處理復雜的控制邏輯和大規模數據輸入輸出，滿足快速響應的工業自動化需求。
多種通信接口：
- 支持與各種 I/O 模塊和其他控制系統的通信接口，如 Modbus、Ethernet/IP 等，確保數據傳輸?shù)母咝Ш头€(wěn)定。
模塊化設計：
- 該處理器模塊采用模塊化設計，便于系統擴展和維護。用戶可以根據具體需求靈活配置系統，確保滿足不同應用場合的要求。
自診斷功能：
- 內置的自診斷功能能夠?qū)崟r監控模塊的運行狀態，及時發現和報告潛在問題，便于維護人員快速響應。
技術規格
處理器架構：
- 三重模塊冗余 (TMR)，每個模塊獨立處理相同任務，投票機制確保輸出的可靠性。
安全等級：
- 符合 SIL 3 安全等級要求，適用于高安全性要求的應用領域。
通信接口：
- 支持多種工業標準通信協議，如 Modbus、Ethernet/IP 等，能夠與各種 I/O 模塊和其他系統進行無縫集成。
電源要求：
- 通常需要 24V DC 電源，具體電源需求可能因系統配置而異。
環境適應性：
- 設計適應工業環境中的各種挑戰，如高溫、潮濕、振動和電磁干擾等。
英文資料：
Triconex A03481S2 is a triple redundant processor module that is an important component of the Triconex series of security systems. This module is designed specifically for industrial environments with critical tasks and high security requirements, utilizing a Triple Modular Redundancy (TMR) architecture to provide highly reliable control and protection functions.
Main features and functions
Triple Modular Redundancy (TMR) architecture:
The A03481S2 module adopts TMR architecture and consists of three independent, parallel processing units. Each processing unit processes the same task simultaneously, and the final output is determined through a voting mechanism to ensure that the system can operate normally even when one processing unit fails. This design greatly improves the reliability and safety of the system.
High security:
The module complies with SIL 3 safety level and is an ideal choice for high safety applications. It provides excellent fault detection and fault tolerance capabilities in industrial automation and safety protection systems, ensuring reliable operation of the system in critical tasks.
Real time processing and control:
A03481S2 has powerful real-time processing capabilities, capable of handling complex control logic and large-scale data input and output, meeting the fast response requirements of industrial automation.
Multiple communication interfaces:
Support communication interfaces with various I/O modules and other control systems, such as Modbus, Ethernet/IP, etc., to ensure efficient and stable data transmission.
Modular design:
The processor module adopts a modular design, which facilitates system expansion and maintenance. Users can flexibly configure the system according to specific needs to ensure that it meets the requirements of different application scenarios.
Self diagnostic function:
The built-in self diagnostic function can monitor the running status of the module in real time, detect and report potential problems in a timely manner, and facilitate maintenance personnel to respond quickly.
technical specifications
Processor architecture:
Triple Modular Redundancy (TMR), where each module independently handles the same task and the voting mechanism ensures the reliability of the output.
Security level:
Meets SIL 3 safety level requirements and is suitable for applications with high safety requirements.
Communication interface:
Supports multiple industrial standard communication protocols, such as Modbus, Ethernet/IP, etc., and can seamlessly integrate with various I/O modules and other systems.
Power requirements:
Usually requires a 24V DC power supply, specific power requirements may vary depending on system configuration.
Environmental adaptability:
Design to adapt to various challenges in industrial environments, such as high temperature, humidity, vibration, and electromagnetic interference.
2.產 品 展 示
