3BSE013064R1輸出個性模塊,3BSE013064R1產品重量
主要關注的是響應時間和系統穩定性
在確定控制器增益時。模擬控制調諧的目標是在保持系統穩定性的同時具有高頻響應。液壓伺服模塊是一個比例積分微分控制器（PID）。PID控制器很容易滿足模擬控制調諧目標。
PID控制器的導數作用增加并穩定通過補償延遲時間的頻率響應控制回路。
PID控制器很復雜，很難對其進行調整。這個最常見的調諧方法（90%到95%的時間）
3BSE013064R1輸出個性模塊PID控制器是一種試錯或?qū)嵱玫姆椒?。這個HSS模塊采用導數和積分作用設計常數（不可調）。調整是通過改變比例增益。增加比例增益降低系統穩定性并增加頻率響應。
實用方法發現增益低于導致不穩定（振蕩）的增益。設置控制器增益的實用方法需要具有渦輪機控制經驗的獨立人員。單獨調諧該系統應熟悉正常條件下的電廠運行，了解汽輪機啟動程序，并具有具有調節控制系統的經驗。如果閥門是與控制柜的距離或由屏障隔開，需要兩個人來調整系統。一個人觀察另一人設置控制器時閥門的操作獲得并輸入職位需求。建議通過電話或?qū)χv機進行通信。對講機的射頻干擾可能會導致控制系統。如果使用對講機，請格外小心。
在對裝置進行鍵控時，操作員應至少兩人距離機柜米，機柜門關閉。
Response time and system stability are the primary concerns
in determining the controller gain. The objective of analog control tuning is to have a high frequency response while maintaining system stability. The hydraulic servo module is a
proportional plus integral plus derivative controller (PID). PID
controllers readily meet the analog control tuning objectives.
The derivative action of PID controllers increases and stabilizes
the frequency response by compensating for lag time in the
control loop.
PID controllers are complex and tuning them is difficult. The
most common method (90 to 95 percent of the time) of tuning
PID controllers is the trial and error or practical method. The
HSS module is designed with the derivative and integral action
constant (not tunable). Tuning is accomplished by changing
the proportional gain. Increasing the proportional gain
decreases system stability and increases frequency response.
The practical method finds the gain that is one level below the
gain that causes instability (oscillation).The practical method of setting controller gain requires an individual with turbine control experience. The individual tuning
the system should be familiar with plant operation under normal conditions, know turbine start-up procedures and have
experience in tuning control systems. In cases where the valve
is a distance from the control cabinet or separated by barriers,
two people are needed to tune the system. One person observes
the valve operation while the other person sets the controller
gain and enters position demand. Communication by telephone or intercom is recommended. The radio frequency interference from walkie-talkies can cause problems with the
control system. Exercise extreme care if using a walkie-talkie.
When keying the unit, the operator should be at least two
meters away from the cabinet and the cabinet doors closed.
