機器故障計時器超時。
狀態LED/紅色和輸出顯示LED/on。重置IMHSS03。
1.轉動面板上的指旋螺釘?-轉動以解鎖模塊。
2.拉動模塊面板，直到模塊與MMU背板連接器斷開連接。
3.推動模塊面板，重新放置模塊直到模塊與MMU背板連接。
4.轉動面板指旋螺釘?-圈，直到模塊鎖定到位。
重置模塊和機器故障計時器超時繼續。
DSQC604機器人模塊狀態LED/紅色和輸出顯示LED/on。更換IMHSS03。
1.轉動面板上的指旋螺釘?-轉動以解鎖模塊。
2.拉動模塊面板，將模塊從MMU。參考第3節和第4節安裝和校準更換模塊。斷電。所有LED熄滅。1、取下IMHSS03，檢查系統電源。有關詳細信息，請參閱相應的電力系統說明故障排除程序。斷電和系統功率檢查良好。所有LED熄滅。更換IMHSS03。
1.轉動面板上的指旋螺釘?-轉動以解鎖模塊。
2.拉動模塊面板，將模塊從MMU。參考第3節和第4節安裝和校準更換模塊。Machine fault timer
time-out.
Status LED/red and
OUT DIS LED/on.
Reset IMHSS03.
1. Turn the thumbscrews on the faceplate ?-turn to unlock
the module.
2. Pull on the module faceplate until the module discon
nects from the MMU backplane connector.
3. Reseat the module by pushing on the module faceplate
until the module connects with the MMU backplane connec
tor.
4. Turn the faceplate thumbscrews ?-turn until the module
locks in place.
Reset module and
machine fault timer
time-out continues.
Status LED/red and
OUT DIS LED/on.
Replace IMHSS03.
1. Turn the thumbscrews on the faceplate ?-turn to unlock
the module.
2. Pull on the module faceplate, remove the module from
the MMU.
3. Refer to Sections 3 and 4 to install and calibrate the
replacement module.
Loss of power. All LEDs off. 1. Remove IMHSS03 and check the system power.
2. Refer to the appropriate power system instruction for
troubleshooting procedures.
Loss of power and
system power
checks good.
All LEDs off. Replace IMHSS03.
1. Turn the thumbscrews on the faceplate ?-turn to unlock
the module.
2. Pull on the module faceplate, remove the module from
the MMU.
3. Refer to Sections 3 and 4 to install and calibrate the
replacement module.
