Multilin 5500P面板儀表 PDF資料
1.產 品 資 料 介 紹：
中文資料：
Multilin 5500P 面板儀表是 GE Multilin 系列中的一種高性能多功能面板儀表，用于電力系統和工業應用中實時監測、測量和顯示電氣參數。它提供了廣泛的測量功能和靈活的配置選項，適用于各種電力和自動化系統的監控需求。
主要應用領域
電力系統監測
- 用于發電廠、變電站和配電系統中，實時監測電氣參數如電壓、電流、功率、頻率等。
- 幫助操作人員和工程師實時了解電力系統的狀態，進行故障檢測和分析。
工業自動化
- 在工業自動化系統中，用于監測和顯示關鍵電氣參數，支持設備的運行和維護。
- 適用于制造業、石油化工、礦業等領域的自動化控制系統。
變電站控制
- 用于變電站中，提供實時數據和狀態顯示，支持變電站的監控和控制。
- 提供警報和診斷功能，確保變電站的安全和可靠運行。
主要特點
多功能測量
- 提供電壓、電流、功率、功率因數、頻率等多種電氣參數的測量和顯示。
- 支持對三相和單相系統的測量，適應不同的應用需求。
實時數據監控
- 提供實時數據顯示和歷史數據記錄，幫助操作人員監控系統狀態。
- 支持實時趨勢圖和數據分析，輔助決策和故障排查。
靈活的配置選項
- 允許用戶根據需求配置測量范圍、報警設置和顯示格式。
- 支持多種通信協議和接口，方便與其他系統集成。
用戶友好的界面
- 提供直觀的觸摸屏或按鍵操作界面，便于用戶進行設置和操作。
- 支持多語言顯示，適應不同地區和用戶的需求。
高可靠性和耐用性
- 設計用于工業環境，具備防塵、防水和抗電磁干擾功能。
- 確保在惡劣環境中長期穩定運行，減少維護需求。
報警和診斷功能
- 內置報警系統，能夠檢測和報告超出設定范圍的電氣參數。
- 提供故障診斷功能，幫助用戶快速定位和解決問題。
英文資料：
The Multilin 5500P panel instrument is a high-performance multifunctional panel instrument in the GE Multilin series, used for real-time monitoring, measurement, and display of electrical parameters in power systems and industrial applications. It provides a wide range of measurement functions and flexible configuration options, suitable for monitoring needs of various power and automation systems.
Main application areas
Power system monitoring
Used for real-time monitoring of electrical parameters such as voltage, current, power, frequency, etc. in power plants, substations, and distribution systems.
Assist operators and engineers in real-time understanding the status of the power system, conducting fault detection and analysis.
industrial automation
In industrial automation systems, it is used to monitor and display key electrical parameters, support equipment operation and maintenance.
Suitable for automation control systems in manufacturing, petrochemical, mining and other fields.
Substation control
Used in substations to provide real-time data and status display, supporting monitoring and control of substations.
Provide alarm and diagnostic functions to ensure the safe and reliable operation of the substation.
main features
Multi functional measurement
Provide measurement and display of various electrical parameters such as voltage, current, power, power factor, frequency, etc.
Support measurement of three-phase and single-phase systems to meet different application requirements.
Real time data monitoring
Provide real-time data display and historical data recording to assist operators in monitoring system status.
Support real-time trend charts and data analysis to assist in decision-making and troubleshooting.
Flexible configuration options
Allow users to configure measurement ranges, alarm settings, and display formats according to their needs.
Supports multiple communication protocols and interfaces, facilitating integration with other systems.
User friendly interface
Provide an intuitive touch screen or button operation interface for users to easily set up and operate.
Support multilingual display to meet the needs of different regions and users.
High reliability and durability
Designed for industrial environments, it has dust-proof, waterproof, and anti electromagnetic interference functions.
Ensure long-term stable operation in harsh environments and reduce maintenance requirements.
Alarm and diagnostic functions
Built in alarm system capable of detecting and reporting electrical parameters beyond the set range.
Provide fault diagnosis function to help users quickly locate and solve problems.
2.產 品 展 示
