Multilin GEHD2CAB電機保護系統 PDF資料
1.產 品 資 料 介 紹：
中文資料：
Multilin GEHD2CAB 是 GE Multilin 系列中的一種電機保護系統，專為電機保護、監控和控制而設計。該系統集成了多種功能，用于提升電機系統的安全性、可靠性和效率。
主要應用領域
電力系統
- 用于發電廠、變電站和配電系統中，對電動機進行保護和控制。
- 保障電力系統中電機的安全運行，防止電機故障導致系統停機或設備損壞。
工業自動化
- 在工業自動化系統中，提供電動機的全面保護，確保生產過程的連續性和設備的可靠性。
- 適用于制造業、礦業、石油化工等行業中的電機控制和保護需求。
變電站
- 在變電站中用于對電動機進行精確的保護和監控。
- 提供實時數據和報警功能，支持變電站的自動化控制和維護。
主要特點
多功能保護
- 提供過載保護、短路保護、欠壓保護、過壓保護、缺相保護等多種保護功能。
- 支持電流、電壓、功率因數等參數的實時監控和控制。
先進的監控功能
- 實時監控電機的運行狀態，包括電流、電壓、溫度、頻率等。
- 提供詳細的歷史數據和趨勢分析，幫助預防潛在故障。
智能報警和診斷
- 內置智能報警系統，可設置不同的報警級別和響應措施。
- 提供故障診斷功能，幫助快速定位和解決問題。
靈活的通信接口
- 支持多種通信協議，如Modbus、DNP3、Profibus等，方便與其他系統集成。
- 提供以太網、RS485和RS232接口，支持遠程監控和數據傳輸。
用戶友好的界面
- 提供直觀的用戶界面，便于操作和配置。
- 支持圖形化顯示和觸摸屏操作，提升用戶體驗。
高可靠性和耐用性
- 設計用于工業環境，具備防塵、防水和抗電磁干擾功能。
- 確保在惡劣的工作條件下長期穩定運行。
英文資料：
Multilin GEHD2CAB is a motor protection system in the GE Multilin series, designed specifically for motor protection, monitoring, and control. This system integrates multiple functions to enhance the safety, reliability, and efficiency of the motor system.
Main application areas
Power system
Used for protecting and controlling electric motors in power plants, substations, and distribution systems.
Ensure the safe operation of motors in the power system and prevent motor failures from causing system shutdown or equipment damage.
industrial automation
In industrial automation systems, comprehensive protection of electric motors is provided to ensure the continuity of production processes and the reliability of equipment.
Suitable for motor control and protection needs in industries such as manufacturing, mining, and petrochemicals.
transformer substation
Used in substations for precise protection and monitoring of electric motors.
Provide real-time data and alarm functions to support automation control and maintenance of substations.
main features
Multi functional protection
Provide multiple protection functions such as overload protection, short circuit protection, undervoltage protection, overvoltage protection, and phase loss protection.
Support real-time monitoring and control of parameters such as current, voltage, and power factor.
Advanced monitoring functions
Real time monitoring of the motor's operating status, including current, voltage, temperature, frequency, etc.
Provide detailed historical data and trend analysis to help prevent potential failures.
Intelligent alarm and diagnosis
Built in intelligent alarm system, which can set different alarm levels and response measures.
Provide fault diagnosis function to help quickly locate and solve problems.
Flexible communication interface
Supports multiple communication protocols, such as Modbus, DNP3, Profibus, etc., making it easy to integrate with other systems.
Provide Ethernet, RS485, and RS232 interfaces, supporting remote monitoring and data transmission.
User friendly interface
Provide an intuitive user interface for easy operation and configuration.
Support graphical display and touch screen operation to enhance user experience.
High reliability and durability
Designed for industrial environments, it has dust-proof, waterproof, and anti electromagnetic interference functions.
Ensure long-term stable operation under harsh working conditions.
2.產 品 展 示
