MULTILIN MMII-PD-1-2-MO電機管理器 PDF資料
1.產 品 資 料 介 紹：
中文資料：
MULTILIN MMII-PD-1-2-MO 是 GE 的 MULTILIN 系列中的一款電機管理器，專門用于電機的保護、監控和控制。這個電機管理器提供了全面的功能來確保電機系統的安全和高效運行。以下是關于 MMII-PD-1-2-MO 電機管理器的詳細信息：
主要特性和功能
電機保護功能：
- 過載保護： 監測電機的電流，防止因負載過大而導致的電機損壞。
- 堵轉保護： 檢測電機啟動時的電流，如果電機堵轉，則觸發保護機制。
- 斷相保護： 檢測電源缺相或不平衡，防止因缺相或相不平衡對電機造成的損壞。
- 過電壓和欠電壓保護： 保護電機免受電壓異常的影響。
- 短路保護： 監測電流異常情況，防止短路對電機造成的損壞。
監控與診斷：
- 實時監控： 顯示電機的運行狀態，如電流、電壓、功率等關鍵參數。
- 故障診斷： 提供詳細的故障記錄和診斷信息，有助于快速定位和解決問題。
- 數據記錄： 存儲歷史數據和事件記錄，便于后續分析和審計。
通信與集成：
- 通信協議： 支持標準的通信協議，如 Modbus、DNP3 和 IEC 61850，方便與上級控制系統或遠程監控系統集成。
- 遠程監控： 通過通信接口支持遠程配置、監控和故障排除。
用戶界面：
- 顯示屏： 配備 LCD 顯示屏，用于實時顯示電機參數和狀態。
- 操作界面： 提供直觀的操作界面，便于配置和調整保護設置。
應用領域：
- 工業自動化： 在工業環境中用于電機的保護和控制，確保設備的穩定運行。
- 發電和配電系統： 適用于發電機組和配電系統中的電機保護。
- 水處理和泵站： 用于水處理設施和泵站中的電機管理和保護。
英文資料：
MULTILIN MMII-PD-1-2-MO is a motor manager in GE's MULTILIN series, specifically designed for motor protection, monitoring, and control. This motor manager provides comprehensive functionality to ensure the safe and efficient operation of the motor system. The following is detailed information about the MMII-PD-1-2-MO motor manager:
Main features and functions
Motor protection function:
Overload protection: Monitor the current of the motor to prevent motor damage caused by excessive load.
Locking protection: detects the current when the motor starts, and if the motor is locked, triggers the protection mechanism.
Phase loss protection: detects power supply phase loss or imbalance to prevent damage to the motor caused by phase loss or imbalance.
Overvoltage and undervoltage protection: protects the motor from the effects of abnormal voltage.
Short circuit protection: Monitor abnormal current conditions to prevent damage to the motor caused by short circuits.
Monitoring and Diagnosis:
Real time monitoring: Display the operating status of the motor, such as key parameters such as current, voltage, and power.
Fault diagnosis: Providing detailed fault records and diagnostic information helps to quickly locate and solve problems.
Data recording: Store historical data and event records for subsequent analysis and auditing.
Communication and Integration:
Communication Protocol: Supports standard communication protocols such as Modbus, DNP3, and IEC 61850, facilitating integration with higher-level control systems or remote monitoring systems.
Remote monitoring: supports remote configuration, monitoring, and troubleshooting through communication interfaces.
User interface:
Display screen: Equipped with an LCD display screen for real-time display of motor parameters and status.
Operation interface: Provides an intuitive operation interface for configuring and adjusting protection settings.
Application areas:
Industrial automation: used for motor protection and control in industrial environments to ensure stable operation of equipment.
Power generation and distribution system: suitable for motor protection in generator sets and distribution systems.
Water treatment and pumping stations: used for motor management and protection in water treatment facilities and pumping stations.
2.產 品 展 示
