Multilin F650BABF1G0HIS數字間隔控制器
1.產 品 資 料 介 紹：
中文資料：
Multilin F650BABF1G0HIS 是 GE Multilin 系列中的數字間隔控制器，主要用于電力系統中的間隔保護和控制。以下是該控制器的詳細信息及其應用領域：
主要功能和特點：
間隔保護：
- 斷路器間隔控制：用于監控和控制斷路器之間的間隔，確保電力系統的穩定性和安全性。
- 故障隔離：在發生故障時，控制器能夠快速隔離故障區域，防止故障擴散到系統的其他部分。
實時監控：
- 狀態監測：實時監控系統中的斷路器狀態和電氣參數，如電流、電壓、功率等。
- 故障檢測：檢測和記錄系統中的故障事件，支持故障分析和診斷。
控制功能：
- 自動控制：支持自動控制功能，如斷路器的自動合閘和斷開，優化系統運行。
- 手動控制：提供手動控制選項，方便操作員進行人工干預和調整。
通訊能力：
- 多種通訊協議：支持多種通訊協議，如Modbus、DNP3、IEC 61850等，方便與其他系統進行集成。
- 數據接口：提供多種數據接口，支持?jǐn)?shù)據傳輸和系統集成。
配置和安裝：
- 靈活配置：支持多種配置選項，滿足不同應用場景的需求。
- 易于安裝：設計便于安裝和維護，簡化了設備的安裝和操作過程。
應用領域：
變電站：
- 間隔保護：為變電站中的斷路器提供間隔保護，確保電力系統的安全運行。
- 故障隔離：在變電站發生故障時，迅速隔離故障區域，防止故障對整個系統造成影響。
發電廠：
- 發電機組保護：保護發電廠中的發電機組和變壓器，防止故障擴散和設備損壞。
- 電力分配：優化發電廠的電力分配系統，提高系統的穩定性和可靠性。
配電系統：
- 配電線路保護：為配電系統中的斷路器提供保護，確保配電線路的正常運行。
- 負荷管理：監控和管理配電系統中的負荷，防止過載和設備故障。
工業設施：
- 工廠電力保護：為工業設施中的電力系統提供保護和控制，防止設備故障和生產中斷。
- 自動化系統：支持工業自動化系統中的間隔保護和控制，優化生產過程。
新能源發電：
- 風電場：保護風電場中的電力系統，確保風力發電系統的穩定運行。
- 太陽能電站：為太陽能電站提供間隔保護和控制，優化太陽能發電系統的性能。
交通運輸：
- 鐵路系統：保護鐵路電力系統中的斷路器，確保鐵路設施的正常運行。
- 地鐵系統：為地鐵系統提供間隔保護，確保地鐵運營的安全性。
英文資料：
Multilin F650BABF1G0HIS is a digital interval controller in the GE Multilin series, mainly used for interval protection and control in power systems. The following is the detailed information and application areas of the controller:
Main functions and features:
Interval protection:
Circuit breaker interval control: used to monitor and control the interval between circuit breakers, ensuring the stability and safety of the power system.
Fault isolation: In the event of a fault, the controller can quickly isolate the fault area to prevent the fault from spreading to other parts of the system.
Real time monitoring:
Status monitoring: Real time monitoring of circuit breaker status and electrical parameters in the system, such as current, voltage, power, etc.
Fault detection: Detecting and recording fault events in the system, supporting fault analysis and diagnosis.
Control function:
Automatic control: supports automatic control functions, such as automatic closing and opening of circuit breakers, to optimize system operation.
Manual control: Provides manual control options for operators to easily intervene and adjust manually.
Communication ability:
Multiple communication protocols: Supports multiple communication protocols such as Modbus, DNP3, IEC 61850, etc., making it easy to integrate with other systems.
Data interface: Provides multiple data interfaces, supports data transmission and system integration.
Configuration and installation:
Flexible configuration: Supports multiple configuration options to meet the needs of different application scenarios.
Easy to install: The design is easy to install and maintain, simplifying the installation and operation process of the equipment.
Application areas:
Substation:
Interval protection: Provide interval protection for circuit breakers in substations to ensure the safe operation of the power system.
Fault isolation: In the event of a fault in the substation, quickly isolate the fault area to prevent the fault from affecting the entire system.
power plant:
Generator set protection: protects the generator sets and transformers in the power plant, preventing the spread of faults and equipment damage.
Power distribution: Optimize the power distribution system of power plants to improve system stability and reliability.
Power distribution system:
Distribution line protection: provides protection for circuit breakers in the distribution system to ensure the normal operation of distribution lines.
Load management: Monitor and manage the load in the distribution system to prevent overload and equipment failure.
Industrial facilities:
Factory power protection: provides protection and control for the power system in industrial facilities, preventing equipment failures and production interruptions.
Automation system: supports interval protection and control in industrial automation systems, optimizing production processes.
New energy generation:
Wind farm: Protect the power system in the wind farm and ensure the stable operation of the wind power generation system.
Solar power station: providing interval protection and control for solar power stations, optimizing the performance of solar power generation systems.
Transportation:
Railway system: Protect the circuit breakers in the railway power system to ensure the normal operation of railway facilities.
Subway system: Provide interval protection for the subway system to ensure the safety of subway operation.
2.產 品 展 示
