Multilin F60C00HCHF8AH6繼電器面板
1.產 品 資 料 介 紹：
中文資料：
Multilin F60C00HCHF8AH6 繼電器面板是 GE Multilin 系列的一部分，專為配電和變電站應用設計，提供全面的饋線保護和控制功能。該繼電器面板具備多種保護、監測和控制功能，適用于各種電力系統環境。
主要功能和特點
饋線保護
- 過流保護：提供瞬時、定時限和反時限過流保護，確保在故障情況下快速響應并隔離故障。
- 接地保護：具備接地故障保護功能，監測和保護接地故障，防止設備損壞和停電事故。
電壓保護
- 過壓和欠壓保護：保護系統免受電壓異常影響，確保設備和系統的穩定運行。
- 零序電壓保護：用于檢測和保護接地故障，提供額外的保護層。
頻率保護
- 頻率過高和過低保護：監測系統頻率，防止頻率異常引起的系統不穩定和設備損壞。
斷路器控制
- 自動重合閘功能：在故障清除后，自動重合閘功能可提高系統的供電可靠性。
- 斷路器失靈保護：檢測斷路器失靈情況，并迅速采取措施隔離故障區域。
通信和接口
- 多種通信協議：支持 Modbus、DNP3、IEC 61850 等通信協議，確保與其他系統的兼容性。
- 標準接口：提供以太網、RS-232 和 RS-485 接口，便于與外部設備和系統進行數據交換。
數據記錄和事件分析
- 故障記錄：記錄故障事件的詳細信息，便于事后分析和故障排查。
- 事件日志和波形捕捉：捕捉事件發生時的電氣波形，幫助用戶進行深入的事件分析和診斷。
用戶界面和配置
- 直觀的 LCD 顯示屏：配備直觀的顯示屏，用戶可以輕松查看和設置參數。
- 圖形化配置工具：通過圖形化配置工具，用戶可以簡化配置過程，提高工作效率。
- 遠程配置和監控：支持遠程配置和監控功能，方便集中管理和維護。
高可靠性和環境適應性
- 工業級設計：具備高可靠性的設計，能夠適應各種嚴苛的工作環境。
- 寬溫范圍運行：能夠在廣泛的溫度范圍內穩定運行，確保系統的可靠性。
應用領域
變電站
- 主變壓器保護：為變電站中的主變壓器提供全面的保護，防止故障影響系統穩定。
- 母線保護：監測和保護變電站中的母線，防止故障擴大，保障電力系統的穩定性。
輸配電系統
- 線路保護：為輸電線路提供高效的保護，防止故障引發大范圍停電。
- 分段保護：對配電系統中的各個分段進行保護和控制，提高配電網絡的可靠性。
工業電力系統
- 設備保護：保護工業電力系統中的關鍵設備，防止因故障導致的生產中斷。
- 電網穩定性：通過提供全面的保護功能，確保工業電力系統的穩定運行。
總結
Multilin F60C00HCHF8AH6 繼電器面板提供了先進的饋線保護、電壓保護、頻率保護和斷路器控制功能，適用于變電站、輸配電系統和工業電力系統中的關鍵設備保護。其高靈敏度、高可靠性和豐富的通信接口，使其成為電力保護和控制系統中的重要組成部分。
英文資料：
The Multilin F60C00HCHFAH6 relay panel is part of the GE Multilin series, designed specifically for distribution and substation applications, providing comprehensive feeder protection and control functions. This relay panel has multiple protection, monitoring, and control functions, suitable for various power system environments.
Main functions and features
feeder protection
Overcurrent protection: Provides instantaneous, timed, and inverse time overcurrent protection to ensure rapid response and isolation of faults in the event of a malfunction.
Grounding protection: equipped with grounding fault protection function, monitoring and protecting grounding faults, preventing equipment damage and power outage accidents.
Voltage protection
Overvoltage and undervoltage protection: protects the system from abnormal voltage effects and ensures stable operation of equipment and systems.
Zero sequence voltage protection: used to detect and protect ground faults, providing additional protection layer.
Frequency protection
High and low frequency protection: Monitor the system frequency to prevent system instability and equipment damage caused by abnormal frequency.
Circuit breaker control
Automatic reclosing function: After the fault is cleared, the automatic reclosing function can improve the power supply reliability of the system.
Circuit breaker failure protection: detect circuit breaker failure and quickly take measures to isolate the faulty area.
Communication and Interface
Multiple communication protocols: Supports communication protocols such as Modbus, DNP3, IEC 61850, etc., ensuring compatibility with other systems.
Standard interface: Provides Ethernet, RS-232, and RS-485 interfaces for easy data exchange with external devices and systems.
Data recording and event analysis
Fault record: Record detailed information of fault events for post analysis and troubleshooting.
Event logs and waveform capture: Capture the electrical waveform at the time of an event to assist users in conducting in-depth event analysis and diagnosis.
User interface and configuration
Intuitive LCD display: Equipped with an intuitive display screen, users can easily view and set parameters.
Graphical configuration tool: Through graphical configuration tools, users can simplify the configuration process and improve work efficiency.
Remote configuration and monitoring: Supports remote configuration and monitoring functions, facilitating centralized management and maintenance.
High reliability and environmental adaptability
Industrial grade design: With high reliability design, it can adapt to various harsh working environments.
Wide temperature range operation: capable of stable operation over a wide temperature range, ensuring the reliability of the system.
application area
transformer substation
Main transformer protection: provides comprehensive protection for the main transformers in the substation to prevent faults from affecting system stability.
Busbar protection: Monitor and protect the busbars in substations to prevent the expansion of faults and ensure the stability of the power system.
Power transmission and distribution system
Line protection: provides efficient protection for transmission lines to prevent widespread power outages caused by faults.
Segmented protection: Protecting and controlling each segment in the distribution system to improve the reliability of the distribution network.
Industrial power system
Equipment protection: Protecting critical equipment in industrial power systems to prevent production interruptions caused by malfunctions.
Grid stability: By providing comprehensive protection functions, ensure the stable operation of industrial power systems.
summary
The Multilin F60C00HCHFAH6 relay panel provides advanced feeder protection, voltage protection, frequency protection, and circuit breaker control functions, suitable for key equipment protection in substations, transmission and distribution systems, and industrial power systems. Its high sensitivity, high reliability, and rich communication interfaces make it an important component of power protection and control systems.
