雙列直插式開關S2是一個八極雙列直插式開關，用于設置解調器增益。如果配置了模塊，則忽略該雙列直插式開關具有功能代碼55。將解調器增益設置為解調器增益放大反饋信號，使LVDT反饋信號的峰-峰跨度接近可實現全范圍的16位分辨率模數轉換器。如果模塊配置為按照
使用功能代碼150的IMHSS02模塊，該雙列直插式開關必須具有手動LVDT校準的初始設置。參考雙列直插式開關S3是一個設置控制器的八極雙列直插式開關
502476L線路接口模塊獲得如果模塊配置為功能代碼55。將控制器增益設置為1。
該放大器將位置需求與位置反饋進行比較并輸出這些信號的差值?？刂破髟鲆嬗绊懣刂苹芈返捻憫?yīng)。如果使用功能代碼150將模塊配置為IMHSS02模塊，則雙列直插式開關必須具有初始設置。參見控制器在附錄B中進行調諧，以初始設置手動控制器的S2增益調諧。S3雙列直插式開關設置見表3-3。
Dipswitch S4 is a two-pole dipswitch that sets the LVDT oscillator frequency. This dipswitch is ignored if the module is con
figured as an IMHSS03 module using function code 55. Set all
poles to one (open).
If the module is configured as an IMHSS02 module using func
tion code 150, set the LVDT oscillator frequency to the fre
quency specified by the manufacturer. To set the LVDT
oscillator frequency:
1. Refer to the LVDT specifications for the recommended
LVDT primary excitation voltage frequency.
2. Refer to Table 3-4 for dipswitch settings and set S4 so that
the LVDT oscillator meets the manufacturer’s specifications.
Dipswitch S5 - Dither and LVDT Oscillator
Dipswitch S5 is an eight-pole dipswitch that sets the dither
oscillator frequency and amplitude, and the LVDT oscillator
amplitude (LVDT primary excitation voltage).
Set the dither oscillator amplitude and frequency to the value
the manufacturer of the servo valve recommends. Dipswitch
poles one and two set the dither oscillator frequency. Poles
three and four set the dither oscillator amplitude or disables
the dither oscillator circuitry. Poles five through eight set the
LVDT oscillator amplitude. Set the LVDT oscillator amplitude
to the value that the LVDT manufacturer recommends. To set
dipswitch S5:
1. Refer to the servo valve specifications for the recommended
dither oscillator current amplitude and frequency.
2. Refer to Table 3-5 for dipswitch settings and set poles 1
through 4 accordingly.
