MULTILIN 745-W2-P1-G1-H變壓器管
1.產 品 資 料 介 紹：
中文資料：
MULTILIN 745-W2-P1-G1-H 變壓器管理繼電器 是 GE Multilin 系列中的一款專門用于變壓器保護和管理的繼電器。這款繼電器設計用于提供高級的變壓器保護功能，確保電力系統中變壓器的可靠運行。以下是關于 MULTILIN 745-W2-P1-G1-H 變壓器管理繼電器的詳細信息，包括其產品特點和應用領域：
產品特點
綜合保護功能
- 過電流保護：提供對變壓器過電流的保護，防止過載對變壓器的損害。
- 差動保護：差動保護功能可檢測變壓器內部故障，提供快速準確的故障隔離。
- 溫度監測：集成溫度傳感器功能，監測變壓器的溫度，以防止過熱情況。
高可靠性和穩定性
- 工業級設計：設計符合工業標準，確保在各種環境條件下的長期穩定運行。
- 抗干擾能力：具有良好的抗電氣干擾能力，確保信號的準確性和系統的穩定性。
智能監控和診斷
- 實時監控：提供實時監控功能，跟蹤變壓器的運行狀態和性能。
- 故障診斷：具備智能故障診斷功能，可以快速定位和分析故障原因。
用戶友好界面
- 直觀顯示：配有用戶友好的顯示界面，方便操作和狀態查看。
- 配置靈活：提供靈活的配置選項，滿足不同應用需求。
通信和集成
- 多種通信協議：支持多種通信協議，如 Modbus、DNP3 等，方便與其他系統進行集成。
- 數據記錄和分析：支持?jǐn)?shù)據記錄和分析功能，幫助進行維護和性能評估。
應用領域
電力系統
- 變電站：在變電站中用于變壓器的保護和管理，確保變壓器的安全運行。
- 配電網：用于配電網中的變壓器保護，防止因過載或內部故障導致的設備損壞。
工業設施
- 生產設施：在大型工業生產設施中提供變壓器保護，保障電力供應的穩定性。
- 礦山和石油平臺：用于礦山和石油平臺中的變壓器保護，確保惡劣環境下的可靠運行。
數據中心
- 關鍵設備保護：在數據中心中保護關鍵變壓器，避免因電力問題導致的服務中斷。
水處理設施
- 泵站和處理廠：為水泵站和污水處理廠中的變壓器提供保護，確保正常運行。
交通系統
- 軌道交通：在軌道交通系統中保護變壓器，保障系統的穩定運行。
技術規格
- 保護功能：包括過電流保護、差動保護、溫度監測等。
- 輸入/輸出：提供多種輸入和輸出接口，支持靈活配置。
- 通信協議：支持 Modbus、DNP3 等常用通信協議。
- 防護等級：具備適當?shù)姆雷o(hù)等級，如 IP54，適應各種環境條件。
- 工作溫度：通常支持寬范圍的工作溫度，適應不同環境條件。
總結
MULTILIN 745-W2-P1-G1-H 變壓器管理繼電器通過其綜合保護功能、高可靠性和智能監控能力，為電力系統中的變壓器提供了強有力的保護。它的多功能設計和靈活配置使其適用于變電站、配電網、工業設施、數據中心、水處理設施和交通系統中的各種應用場景。
英文資料：
MULTILIN 745-W2-P1-G1-H Transformer Management Relay is a relay in the GE Multilin series specifically designed for transformer protection and management. This relay is designed to provide advanced transformer protection functions, ensuring the reliable operation of transformers in the power system. The following is detailed information about MULTILIN 745-W2-P1-G1-H transformer management relay, including its product features and application areas:
Product Features
Comprehensive protection function
Overcurrent protection: Provides protection against transformer overcurrent to prevent damage to the transformer caused by overload.
Differential protection: The differential protection function can detect internal faults in transformers and provide fast and accurate fault isolation.
Temperature monitoring: Integrated temperature sensor function to monitor the temperature of the transformer to prevent overheating.
High reliability and stability
Industrial grade design: The design meets industrial standards to ensure long-term stable operation under various environmental conditions.
Anti interference capability: It has good resistance to electrical interference, ensuring the accuracy of signals and the stability of the system.
Intelligent monitoring and diagnosis
Real time monitoring: Provides real-time monitoring function to track the operation status and performance of transformers.
Fault diagnosis: Equipped with intelligent fault diagnosis function, it can quickly locate and analyze the cause of faults.
User friendly interface
Intuitive display: equipped with a user-friendly display interface, convenient for operation and status viewing.
Flexible configuration: Provides flexible configuration options to meet different application needs.
Communication and integration
Multiple communication protocols: Supports multiple communication protocols such as Modbus, DNP3, etc., making it easy to integrate with other systems.
Data recording and analysis: Supports data recording and analysis functions to assist in maintenance and performance evaluation.
application area
Power system
Substation: Used for the protection and management of transformers in substations to ensure their safe operation.
Distribution network: Used for transformer protection in the distribution network to prevent equipment damage caused by overload or internal faults.
Industrial facilities
Production facilities: Provide transformer protection in large industrial production facilities to ensure the stability of power supply.
Mines and oil platforms: Used for transformer protection in mines and oil platforms to ensure reliable operation in harsh environments.
Data Center
Key equipment protection: Protect critical transformers in data centers to avoid service interruptions caused by power issues.
Water treatment facilities
Pump stations and treatment plants: Provide protection for transformers in pump stations and sewage treatment plants to ensure normal operation.
traffic system
Rail transit: Protect transformers in the rail transit system to ensure stable operation of the system.
technical specifications
Protection functions: including overcurrent protection, differential protection, temperature monitoring, etc.
Input/Output: Provides multiple input and output interfaces, supporting flexible configuration.
Communication protocol: Supports commonly used communication protocols such as Modbus and DNP3.
Protection level: It has an appropriate protection level, such as IP54, and can adapt to various environmental conditions.
Working temperature: It usually supports a wide range of working temperatures and adapts to different environmental conditions.
summary
The MULTILIN 745-W2-P1-G1-H transformer management relay provides strong protection for transformers in the power system through its comprehensive protection function, high reliability, and intelligent monitoring capability. Its multifunctional design and flexible configuration make it suitable for various application scenarios in substations, distribution networks, industrial facilities, data centers, water treatment facilities, and transportation systems.
2.產 品 展 示
