MULTILIN FMOD136-23饋線保護繼電器
1.產 品 資 料 介 紹：
中文資料：
GE Multilin FMOD136-23 是一款專用于饋線保護的繼電器。它主要用于電力系統中，對饋線進行保護，以確保電力供應的可靠性和穩定性。以下是該繼電器的詳細信息：
產品概述
- 型號：FMOD136-23
- 產品類型：饋線保護繼電器
主要特點
- 保護功能：提供全面的饋線保護功能，包括過電流保護、接地故障保護、欠壓/過壓保護等。
- 高級控制：支持自動重啟、邏輯控制、延時操作等功能，增強了系統的控制能力。
- 實時監控：能夠?qū)崟r(shí)監控饋線的狀態和運行參數，如電流、電壓等。
- 用戶界面：配備用戶友好的圖形界面，便于配置、操作和監控。
- 通信能力：支持多種通信協議（如Modbus、DNP3、IEC 61850），方便與其他設備和系統集成。
技術規格
- 型號：FMOD136-23
- 保護功能：
- 過電流保護：檢測并響應電流超出設定值的情況。
- 接地故障保護：監測接地故障，提供保護措施。
- 欠壓/過壓保護：防止電壓異常對設備造成損壞。
- 控制功能：包括自動重啟、延時操作、邏輯控制等。
- 數據采集：實時采集電流、電壓等參數，并進行分析。
- 顯示與界面：高分辨率顯示屏和用戶友好的操作界面。
- 通訊接口：支持多種通信協議，如Modbus、DNP3、IEC 61850。
- 環境適應性：適應寬廣的工作溫度范圍和濕度條件，適合各種工業環境。
- 安裝方式：支持面板安裝或DIN導軌安裝。
應用領域
- 電力系統保護：用于電力系統中的饋線保護，確保電力供應的安全和穩定。
- 工業自動化：集成到工業自動化系統中，保護饋線設備。
- 建筑電力管理：用于建筑物內的饋線保護和管理，防止設備損壞。
- 能源管理：幫助優化能源使用，提供詳細的監控和保護功能。
安裝與維護
- 安裝：設備通常通過面板或DIN導軌安裝，具體安裝方式請參考產品手冊。
- 維護：設計簡潔，便于日常維護和檢查。建議定期檢查設備狀態和連接線，以確保正常運行。
優勢
- 全面保護：集成多種保護功能，確保饋線的安全運行。
- 靈活控制：提供多種控制選項，適應不同的應用需求。
- 強大通信能力：支持多種通信協議，便于與其他設備和系統集成。
- 用戶友好：直觀的界面和操作功能，簡化了配置和監控過程。
總結
GE Multilin FMOD136-23饋線保護繼電器是一款高性能的保護設備，專為電力系統中的饋線保護設計。其綜合的保護功能、高級控制能力和強大的通信能力使其成為電力和工業應用中的理想選擇。
英文資料：
GE Multilin FMOD136-23 is a relay specifically designed for feeder protection. It is mainly used in power systems to protect feeders and ensure the reliability and stability of power supply. The following is the detailed information of the relay:
Product Overview
Model: FMOD136-23
Product Type: Feedline Protection Relay
main features
Protection function: Provides comprehensive feeder protection functions, including overcurrent protection, ground fault protection, undervoltage/overvoltage protection, etc.
Advanced Control: Supports functions such as automatic restart, logical control, and delayed operation, enhancing the system's control capabilities.
Real time monitoring: capable of monitoring the status and operating parameters of feeders in real time, such as current, voltage, etc.
User Interface: Equipped with a user-friendly graphical interface for easy configuration, operation, and monitoring.
Communication capability: Supports multiple communication protocols (such as Modbus DNP3、IEC 61850）， Facilitate integration with other devices and systems.
technical specifications
Model: FMOD136-23
Protection function:
Overcurrent protection: detects and responds to situations where the current exceeds the set value.
Ground fault protection: Monitor ground faults and provide protective measures.
Undervoltage/Overvoltage Protection: prevents abnormal voltage from causing damage to equipment.
Control functions: including automatic restart, delayed operation, logic control, etc.
Data collection: Real time collection and analysis of parameters such as current and voltage.
Display and Interface: High resolution display screen and user-friendly interface.
Communication interface: Supports multiple communication protocols, such as Modbus, DNP3, IEC 61850.
Environmental adaptability: Suitable for a wide range of working temperatures and humidity conditions, suitable for various industrial environments.
Installation method: Supports panel installation or DIN rail installation.
application area
Power system protection: used for feeder protection in power systems to ensure the safety and stability of power supply.
Industrial automation: integrated into industrial automation systems to protect feeder equipment.
Building power management: used for feeder protection and management inside buildings to prevent equipment damage.
Energy management: Help optimize energy use, provide detailed monitoring and protection functions.
Installation and maintenance
Installation: The equipment is usually installed through a panel or DIN rail. Please refer to the product manual for specific installation methods.
Maintenance: The design is simple and easy to maintain and inspect on a daily basis. It is recommended to regularly check the equipment status and connection wires to ensure normal operation.
advantage
Comprehensive protection: integrates multiple protection functions to ensure the safe operation of the feeder.
Flexible control: Provides multiple control options to adapt to different application needs.
Powerful communication capability: Supports multiple communication protocols, making it easy to integrate with other devices and systems.
User friendly: The intuitive interface and operational functions simplify the configuration and monitoring process.
summary
The GE Multilin FMOD136-23 feeder protection relay is a high-performance protection device designed specifically for feeder protection in power systems. Its comprehensive protection functions, advanced control capabilities, and powerful communication capabilities make it an ideal choice for power and industrial applications.
2.產 品 展 示
