ALSTOM LFCB102差動繼電器
1.產 品 資 料 介 紹：
中文資料：
ALSTOM LFCB102差動繼電器是一種用于電力系統的保護設備，通常用于檢測和保護電力系統中的差動故障。差動繼電器通過比較兩個或多個電流信號，檢測是否存在差動電流，從而判斷電力系統中是否存在故障，如相間短路或接地故障。
主要特點：
- 差動保護：通過比較來自不同電流互感器的電流，檢測電力系統中的差動電流，以發現故障。
- 高靈敏度：能夠檢測微小的差動電流，及時響應故障情況。
- 快速響應：故障檢測后能迅速觸發保護動作，切斷故障電路，防止事故擴大。
- 自診斷功能：具備自檢功能，能夠監測自身工作狀態，確?？煽窟\(yùn)行。
- 多種保護模式：支持多種差動保護模式，如相間差動保護、接地差動保護等，適應不同應用場景。
應用領域：
- 發電廠：用于發電機差動保護，確保發電設備在故障情況下得到及時保護。
- 變電站：用于變壓器差動保護，保護變壓器免受內部故障影響。
- 輸電線路：用于輸電線路差動保護，確保輸電線路的安全運行。
- 工業設施：用于大型工業設施的電力保護系統，保障電力系統的穩定和安全。
- 配電網：用于配電變壓器和配電線路的差動保護，防止局部故障擴展。
具體功能：
- 電流比較：實時比較不同測量點的電流值，檢測差動電流。
- 故障判斷：根據設定的差動電流閾值，判斷是否存在故障。
- 動作指令：在檢測到故障后，發出保護動作指令，切斷故障電路。
- 報警功能：在檢測到故障或異常情況時，發出報警信號，提示操作人員檢查系統。
- 數據記錄：記錄故障事件和運行狀態，便于故障分析和維護管理。
使用注意事項：
- 正確接線：確保電流互感器和繼電器的接線正確，以避免誤動作。
- 定期測試：定期對差動繼電器進行測試，確保其靈敏度和可靠性。
- 環境要求：安裝環境應符合產品說明書的要求，避免潮濕、腐蝕性氣體等對設備的不利影響。
- 參數設置：根據實際應用場景，合理設置差動電流閾值和保護模式。
英文資料：
ALSTOM LFCB102 differential relay is a protective device used in power systems, typically for detecting and protecting differential faults in power systems. Differential relays compare two or more current signals to detect the presence of differential current, thereby determining whether there is a fault in the power system, such as phase to phase short circuit or ground fault.
Main features:
Differential protection: By comparing the currents from different current transformers, the differential current in the power system is detected to detect faults.
High sensitivity: able to detect small differential currents and respond promptly to fault situations.
Quick response: After fault detection, it can quickly trigger protective actions, cut off the faulty circuit, and prevent the accident from expanding.
Self diagnostic function: equipped with self checking function, able to monitor its own working status and ensure reliable operation.
Multiple protection modes: Supports multiple differential protection modes, such as phase to phase differential protection, grounding differential protection, etc., to adapt to different application scenarios.
Application areas:
Power plant: used for differential protection of generators to ensure timely protection of power generation equipment in case of faults.
Substation: Used for transformer differential protection, protecting transformers from internal faults.
Transmission line: used for differential protection of transmission lines to ensure the safe operation of transmission lines.
Industrial facilities: Power protection systems used in large industrial facilities to ensure the stability and safety of the power system.
Distribution network: used for differential protection of distribution transformers and distribution lines to prevent local fault propagation.
Specific functions:
Current comparison: Real time comparison of current values at different measurement points to detect differential current.
Fault diagnosis: Determine whether there is a fault based on the set differential current threshold.
Action command: Upon detecting a fault, issue a protective action command to cut off the faulty circuit.
Alarm function: When a fault or abnormal situation is detected, an alarm signal is issued to prompt the operator to check the system.
Data recording: Record fault events and operating status for easy fault analysis and maintenance management.
Precautions for use:
Correct wiring: Ensure that the wiring of the current transformer and relay is correct to avoid misoperation.
Regular testing: Regularly test differential relays to ensure their sensitivity and reliability.
Environmental requirements: The installation environment should comply with the requirements of the product manual, avoiding adverse effects of moisture, corrosive gases, etc. on the equipment.
Parameter setting: Reasonably set the differential current threshold and protection mode according to the actual application scenario.
