3BHB000272R0001驅動控制器,3BHB000272R0001產品顏色
為安裝的特定插槽設置系統的I/O配置掃描儀。有關更多信息，請參閱第5.1節，配置掃描儀。
保存程序。
向CLX通電。
將CLX PLC置于程序模式，并將程序傳輸至CLX PLC。查看您的有關詳細信息，請參閱編程軟件手冊。
3.5.2運行掃描儀以下步驟描述了如何安裝和設置SST-PB3-CLX-RLL掃描儀：
1、安裝Profibus背板產品安裝。筆記確保卸載任何先前的PROFIBUS安裝，并在安裝新版本的軟件之前，請重新啟動電腦。
3BHB000272R0001驅動控制器有關更多詳細信息，請參閱第5.1.1節，通過RSLogix 5000進行配置
信息如果您使用的是PlantScape，請參閱第5.1.2節，配置通過PlantScape Control Builder。
2、運行安裝程序。提供的Windows 2000/XP/Server 2003中的exe文件安裝CD。此安裝腳本可以選擇為安裝一組工具與SST PROFIBUS背板模塊一起使用。SST-PB3-CLX-RLL掃描儀是背板模塊，應使用此選項安裝配置工具和相關軟件。
選擇：開始菜單>SST PROFIBUS配置。
4、選擇文件>新建。在PROFIBUS設備庫（最左側窗格）中，選擇并拖動SST-PB3-CLX
在網絡視圖（最右側窗格）中添加master。如果使用，請選擇AOP選項
附加配置文件。
If you are using PlantScape, refer to Section 5.1.2, Configuring Through PlantScape
Control Builder.
4.
Set up your system's I/O configuration for the particular slot in which you installed the
scanner. Refer to Section 5.1, Configuring the Scanner, for more information.
5.
Save your program.
6.
Apply power to the CLX.
7.
Put the CLX PLC in Program mode and transfer the program to the CLX PLC. See your
programming software manuals for details.
3.5.2 Getting the Scanner Running
The following steps describe how to install and set up the SST-PB3-CLX-RLL scanner:
1.
Install Profibus Backplane Products Installation.
Note
Ensure that you uninstall any previous PROFIBUS installation and
reboot your PC before installing a new version of the software.
Refer to Section 5.1.1, Configuring Through RSLogix 5000, for more detailed
information. If you are using PlantScape, refer to refer to Section 5.1.2, Configuring
Through PlantScape Control Builder.
2.
Run the setup.exe file from the supplied Windows 2000/XP/Server 2003
installation CD. This installation script has an option to install a set of tools for
use with SST PROFIBUS backplane modules. The SST-PB3-CLX-RLL scanner
is a backplane module and this option should be used to install the Configuration
Tool and associated software.
3.
Open the SST PROFIBUS Configuration Tool window by selecting: Start Menu >
SST PROFIBUS Configuration.
4.
Select File > New.
5.
In the PROFIBUS Device library (left-most pane), select and drag the SST-PB3-CLX
master into the Network view (right-most pane) to add it. Select AOP option if using
Add-on-Profile.
